The feathers and applications of CLW brand water tanker trucks manufactured by Chengli Special Automobile Co., Ltd.
1).Equipped with high power self-suction water pump that characterized by high-pressure and fast speed suction.
2).Equipped with front, rear and side sprinklers and high position sprinkler, and rear working platform.
3).The water cannon which is installed on the working platform can rotate by 360 degree and the water flow can be adjusted into various rain shape. There are straight shape, heavy rain, moderate rain and drizzle etc. The max range can reach 30M.
4).Equipped with fire coupling, flow valves, filter screen and water level gauge.
5).According to customers’ request, the crane, high working platform and spraying machine also can be equipped.
6).Mainly used for washing on urban roads, watering and greening on trees, green belts and lawn and dust full of construction sites. And also used for drinking water delivery and fire fighting function etc.
If you're interested in our water tanekr truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of CLW Brand water tanker truck manufactured by Chengli Special Automobile Co., Ltd. as below.
The main technical parameters of Dongfeng 18cbm-22cbm water tanekr truck manufactured by Chengli Special Automobile Co., Ltd. as below.
|
Main specification
|
|
Product model and name
|
dongfeng 210hp 18cbm-22cbm water truck for sale
|
|
Gross weight(Kg)
|
25000
|
Drive type
|
6X4
|
|
Payload(Kg)
|
15800
|
Overall dimension(mm)
|
9990×2480×3150
|
|
Curb weight(Kg)
|
9005
|
Cab seats
|
3
|
|
Approach/departure angle(°)
|
23/10
|
Front/rear hang(mm)
|
1245/3095,1245/3045
|
|
Axle No.
|
3
|
Wheelbase(mm)
|
4350+1300
|
|
Axle load(Kg)
|
7000/18000
|
Max speed(Km/h)
|
85
|
|
Chassis specification
|
|
Chassis model
|
EQ1258KB3GJ
|
Manufacturer
|
Dongfeng Motor Co.,Ltd
|
|
Brand name
|
Dongfeng
|
Dimension(mm)
|
9360×2462×2880,3230
|
|
Tyre specification
|
10.00-20
|
Tyre No.
|
10
|
|
Steel spring number
|
32/14
|
Front track base(mm)
|
1940
|
|
Fuel type
|
Diesel
|
Rear track base(mm)
|
1860/1860
|
|
Emission standard
|
Euro 3
|
Transmission
|
8 forward gear,1 reverse gear
|
|
Cab
|
One and a half rows cab with optional air condition
|
|
Engine model
|
Engine manufacturer
|
Displacement(ml)
|
Power(Kw)
|
|
B210 33
|
Dongfeng Cummins Engine Co.,Ltd
|
5900
|
155
|
|
Performance
|
|
Tank volume(m³)
|
18(18000liter)
|
Tank material
|
Carbon steel Q235
|
|
Water pump model
|
80QZF-60/90N
|
Water pump flow(m³/h)
|
60
|
|
Watering width(M)
|
≥14
|
Water cannon range (M)
|
≥28
|
Chengli Special Automobile Co., Ltd., which is appointed by the Minister of Industry and Information Technology of China, is a big manufacturer producing all kinds of special trucks. It’s famous for special trucks for environment cleanness, oil, chemical industry and pressure vessel. It has registered trademark “ CHENGLIWEI” and product code: CLW. Our company cooperates with famous chassis, and selling chassis, trucks and trucks’ spare parts. Our company has independent export potency, and has a mount of clients overseas. Our leading productions include more than 300 types of trucks such as Water truck, Fecal suction truck, Sewage suction truck, Garbage truck, Road sweeper, Fuel tank truck, High-altitude operation truck, Truck with crane, Dump truck, Trainer truck, Semitrailer, Fire fighting truck, Refrigerated truck, Van truck, Prime mover, Chemical liquid truck, Bulk cement truck, Concrete mixer truck, Wrecker truck, Pressure vessel, Milk truck, LPG tank truck, etc. Our company has solid technology, flawless inspection, advanced equipments, reliant quality and flexible modes of operation. What’s more, it has roundly passed the certification of ISO9001-2008, the 3C(China Compulsory Certification)and other certifications that export needed. Chengli trucks have always taken the top place in Chinese mart in recent ten years. Chengli have procured remarkable achievements interiorly and oversea, specially since our boss invested in building new big modern industry zone in South Suburb development area of Suizhou City, Hubei, China. This area is named after Chengli Automobile Industry Park. Chengli Company becomes a big star in trucks trade in the middle of China.
CLW trucks have been exported Sudan, Libya, Algeria, Morocco, Ethiopia, Kenya, Tanzania, Uganda, Rwanda, Guinea, Sierra Leone, Ivory Coast, Togo, Benin, Niger, Nigeria, Cameroon, Gabon, Botswana, Democratic Republic of Congo, Zambia, Angola, Mozambique, Botswana, Namibia, Maurtius, Mongolia, Kazakhstan, Uzbekistan, Tajikistan, Kyrgystan, Turkmenistan, Afghanistan, Saudi Arabia, Philippines, Indonesia, Korea, Malaysia, Brunei, Thailand, Vietnam, Kampuchea, Laos, Burma, Mexico, Maldvies, Venezuela, Guyana, Columbia, Ecuador, Peru, Brail, Bolivia, Chile, Uruguay, etc.
More information, please feel free to contact with us.
