2020s hot sale Dongfeng 3,000L kitchen garbage truck, factory sale best price dongfeng swill garbage truck for sale
The side loader garbage compactor trucks adopts dongfeng, FAW, FOTON, SINO TRUK, JAC original chassis, having the functions of perfect structure design, high effect, etc. And the truck body adopts ligh duty designing with large transporting, good sealing, the safe, energy-saving, environmental protection new type compressed structure municipal sanitation vehicles at home and all over the world.
The side loader garbage compactor truck can self-loading and discharging. There is waste bins lifting devices at the side of the truck, suitable for installing 240L waste bins (plastic or steel material). At the same time, the best selling one is the dongfeng 145 side loader garbage compactor with the 10cbm garbage volume, and installed sewage storage tank, storing the sewage from the wastes.
If you're interested in our truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
main parameters of hot sale dongfeng 3m3 kitchen garbage truck manufactured by Chengli Special Automobile Co., Ltd. as below.
|
Dongfeng 3cbm waste food garbage truck
|
|
Total mass(kg)
|
6495
|
Curb mass(kg)
|
3970
|
|
Rated mass(kg)
|
2330
|
Chassis model
|
EQ1060TJ20D3
|
|
Driver cab person
|
3
|
Max speed(km/h)
|
90
|
|
Approach/departure angle
|
19/13
|
Front/rear suspension(mm)
|
1032/1663
|
|
Overall dimension(mm)
|
5995X2000X2700,2900
|
Cargo body dimension(mm)
|
XX
|
|
Axles
|
2
|
Axle load(kg)
|
2595/3900
|
|
Tyre
|
7.00-16,6.50-16,7.00R16,6.50R16
|
Tyre nos.
|
6
|
|
Front tread(mm)
|
1506
|
Rear tread(mm)
|
1466
|
|
Wheelbase(mm)
|
3300
|
Springs
|
8/9+5,6/8+4
|
|
Emission standard
|
GB3847-2005,GB17691-2005Euro Ⅲ
|
Fuel type
|
Diesel
|
|
Engine model
|
Manufacturer
|
Displacement
|
Power
|
|
CY4102-C3F
|
Chaochai power
|
3856
|
70
|
Remark:
1. This kitchen garbage truck adopts 1730mm wide dongfeng original driver cab, the wheelbase: 3300mm, Chaochai 4102 engine, 525 transmission, 2T front bridge, 3.5T Rear Bridge, 7.00-16 nylon tyres; air-cut brake,
2. The tanker volume: 3cbm, adopting Wugang high quality steel, round tanker, the discharging door and the rear door are hydraulic sealed. The effective volume can reach 90 percent.
3. The loading of the waste food garbage truck is done by lifting system of the side hydraulic waste bins, using the common sizes 120L/240L square shape waste bins. The lifting system can locking the waste bins, loading and discharging safely and reliably. The waste bins join the waste slot tog well, assuring non-overflow, non-missing.
4. Hydraulic system is made up of pump, hydraulic valve, sequence valve, and multi-purpose hydraulic cylinders, high-low pressure pipeline, etc. The key parts can choose the original imported ones, assuring the truck working safely and reliably.
5. The technical advantages of the waste food garbage truck
a. good looking, the truck cross section just looks like circular cylinder frame, the longitudinal cross-section looks like trapezoidal frame, the tow sides and the top are circular. The whole truck looks like acute and graceful.
b. the waste bins sealed well with the rear door assembly, adopting special strength rubber sealed, good sealing, avoiding the second pollution.
c. high reliability and safety, using electro-hydraulic control, and also having safety protection switch, making sure working accurately and reliably.
d. The engine output realizes fully automatically, when non-work, the engine in idle mode; when working, the engine speed up automatically.
The opening way of the side loader garbage compactor is hydraulic control, there are two hydraulic cylinders at the both side. And the hydraulic shovel at the front compressed the wastes. All the operation units are controlled by hydraulic rod, easy operating and reliable.
More pictures of hot sale dongfeng wastes food truck manufactured by Chengli SPecial Automobile Co., Ltd. as below.
high quality and best price kitchen swing truck for sale
Chengli Special Automobile Co., Ltd. manufactures and sells side load and rear discharging garbage carrier( also called side loader garbage compactor), which is mainly used for collecting, transporting, discharging working of garbage waste bins of towns. The wastes bins at the side full with wastes is lifted, then dumping the garbage to the garbage van; and the wastes in the van pushed from the front to the rear through the discharging push pedal, making the wastes with high density and even I nthe van until full.
The collecting and transporting mode of side load garbage compactor is the widest mode for collecting and delivering wastes. And the special functions of the side load and compressed garbage carriers is take powder by vehicle engine, then through the Electronic controlled gas, gas controlled liquids and manual to control the hydraulic multi-way valve making the hydrauliuc units working by order. The garbage van and sewer van adopt high quality carbon steel full-sealed welding structure with high strength, light weight, non-second time populltion, etc.
Side load refuse garbage carriers are equippe d with lifting and turnover mechanism, suitable for 120L, 140L, 240L plastic waste buckets or metal waste bins.
Chengli Special Automobile Co., Ltd as the famous manufacturer and supplier of garbage trucks in China since 2004, it could offer garbage compactors, swing arm garbage trucks, sealed garbage trucks, dump garbage trucks, side loader garbage trucks, skip loader garbage trucks, etc. More information, please feel free to contact with us.
