Factory sale bottom price dongfeng 10m3 compression garbage truck,refuse garbage truck, wastes collecting equipment vehicle customized for Kyrgyz Republic
The compressed garbage truck usually called garbage compactor truck, compression garbage truck, waste compactor truck,compactor garbage truck,etc.
The compress garbage truck usually compacts the waste using a hydraulically powered mechanism that employs a moving plate or shovel to scoop the waste out from the loading hopper and compress it against a moving wall. In most compactor designs, the plate has a pointed edge (hence giving it the industry standard name packer blade) which is designed to apply point pressure to the waste to break down bulky items in the hopper before being drawn into the main body of the truck.
As a professional special vehicle manufacturer in China, the garbage compression truck we produce is from 4cbm to 20cbm
main technical parameters of CLW Brand 10m3 170hp diesel compression garbage truck as below
| CLW 4*2 LHD 10m3 125KW diesel garbage compactor truck |
| Total mass(kg) |
11495 |
Curb mass(kg) |
8500 |
| Rated mass(kg) |
2800 |
Chassis model |
EQ |
| Driver cab person |
3 |
Max speed(km/h) |
90 |
| Approach/departure angle(°) |
33/11,33/13 |
Front/rear suspension(mm) |
1250/2550 |
| Overall dimension(L*W*H)(mm) |
7750X2495X3350 |
Cargo body dimension(mm) |
XX |
| Axle nos. |
2 |
Axle load(kg) |
4195/7300 |
| Tyre specifications |
9.00-20 |
Tyre nos. |
6 |
| Front tread(mm) |
1900,1810 |
Rear tread(mm) |
1800 |
| Wheelbase(mm) |
3950 |
Springs |
8/11+8 |
| Emission standard |
GB3847-2005,GB17691-2005 Euro Ⅲ |
Fuel type |
Diesel |
| Engine model |
Manufacturer |
Displacement(ml) |
Power (KW) |
| B170 33 |
Dongfeng Cummins |
5900 |
125 |
| 1 |
Product manufacturer |
Chengli Special Automobile Co., Ltd.
|
| 2 |
Chassis model |
EQ
|
| 3 |
Engine model |
Dongfeng Cummins diesel engine, B170 33 6 cylinders turbocharged intercooled |
| 4 |
Engine power(kw) |
125kw/170hp |
| 5 |
Emission standard |
EURO 3 |
| 6 |
Brake |
Air brake |
| 7 |
Shift box |
datong 6 speed transmission, manual |
| 8 |
oil consumption (100km) |
18L |
| 9 |
Max speed |
90kw/h |
| 10 |
Mini turn radius |
18m |
| 11 |
Max climbable gradient |
25﹪ |
| 12 |
wheelbase |
3950(mm) |
| 13 |
Total mass (kg) |
11495 |
| 14 |
Curb mass (kg) |
6800 |
| 15 |
Rated mass (kg) |
4500kgs |
| 16 |
Volume |
10m3 |
| 17 |
Fuel type |
Diesel |
| 18 |
Basket lifting angle |
≥45° |
| 19 |
Charging and discharging way |
Flip bucket mechanism |
| 20 |
Loading working cycle time(s) |
≤22 |
| 21 |
Discharging working cycle time(s) |
≤30 |
| 22 |
Overall dimension(L*W*H)(mm) |
7750X2495X3350 |
| 23 |
maximum compression pressure |
≥150KN, |
| 24 |
Maximum shirk force |
≥180KN |
More picutres of hot sale CLW brand 10m3 compacted garbage truck for Kyrgyz Republic as below
HOT SALE! Dongfeng 10m3 garbage compacted truck for sale
Customized 10m3 compression garbage truck for sale
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of garbage wastes trucks in China, garbage dump truck, garbage compactor truck, swing garbage truck, hook lifter garbage truck, side self-loading garbage truck, etc.
Our CLW brand garbage compactor truck is constructed with 12# low alloy steel 4mm, 5mm, 10mm steel. The body is fitred on the chassis by the truck beam. The body floor is fully sealed. All the sewage can go directly into the sewage tank, so as no to corrode the body and chassis. Moreover, it can also prevent the sewage leakage while the truck is driving on the road and avoid the secondary pollution.
