HOT SALE! best seller-dongfeng 4*2 LHD 7m3 compression garbage compactor truck, new rear loader garbage vehicle for sale
The garbage compactor trucks manufactured by Chengli Special Automobile Co., Ltd. is also called rear loader garbage truck, wastes collecting vehicles, etc. This kind of garbage truck is a kind of special purpose vehicle, mainly used for collecting, transporting and discharging bagged wastes, barreled wastes, bulk household wastes in towns and cities, etc.
The wastes is pressured and pushed into the wastes van by the truck mounted wastes propeller (also called negative pressure mechanism), so that making the wastes distributing into the tank evenly and higher density and till full.
The collecting and transporting way of the garbage compactor truck adopts widely all over the world. The function of the entire special device adopts the truck engine as power, realizing by hydraulic mechanism manual or electronic control.
The wastes van and the loader, which is also called wastes tan and sewer tank, adopting high quality carbon steel with full-sealed welding structure, with the advantages of high strength, light weight, non second pollution, etc.
Operation way of compacted garbage truck manufactured by Chengli Special Automobile Co., Ltd. as below.
1, PLC control system;
2, loading and discharging way: rear loading wastes bins mechanism;
3, compacting way: Bi-directional compression; wastes compacting density≥0.8T/m³; 4, one working circle time for loading and discharging ≤30s;
5, max compressing force≥150KN; max passing force≥180KN.
If you're interested in our compacted garbage truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat: +86 13329899995.
More pictures of dongfeng 4*2 LHD 7M3 compression garbage truck as below
HOT SALE! customized dongfeng 4*2 LHD 7m3 garbage compactor truck
high quality and competitive price dongfeng 7m3 compression garbage truck for sale
main technical parameters of dongfeng 4*2 LHD 7m3 garbage compactor truck as below
| 1 |
Product name |
Dongfeng 4*2 LHD 7m3 garbage compactor truck
|
| 2 |
Truck chassis model |
EQ1070
|
| 3 |
Overall dimension(L*W*H) |
7000*2320*2900
|
| 4 |
Total mass(kgs) |
7490 |
| 5 |
Curb mass(kgs) |
6095 |
| 6 |
Rated mass(kgs) |
1200 |
| 7 |
Volume |
7m3 |
| 8 |
Real loading capacity |
About 6tons |
| 9 |
Max speed |
95kw/h |
| 10 |
Wheelbase |
3800 |
| 11 |
Axle nos. |
2 |
| 12 |
Driver cab |
Dongfeng 4*2 single row driver cab with 3 seats with power steering and without air conditioner. Air conditioner is selective |
| 13 |
Approach/departure angle(°) |
20/11 |
| 14 |
Front/rear suspension (mm) |
1180/2020 |
| 15 |
Front/rear tread(mm) |
1835/1640 |
| 16 |
Tire specification |
7.50R16*6 |
| 17 |
Spring |
11/9+7 |
| 18 |
Engine model |
CY4102 chaochai diesel engine |
| 19 |
Rated power |
88KW/120hp |
| 20 |
Displacement(ml) |
3856ml |
| 21 |
Fuel type |
Diesel |
| 22 |
Emission standard |
Euro 3 |
| 23 |
Gearbox |
5 speed gearbox, manual |
| 24 |
Front/rear axle |
2.5tons/5tons |
| 25 |
Color |
Different color upon request |
| 26 |
Wastes van |
Solid arc-shape box body of strength beam and steel plate welded |
| 27 |
Wastes van material |
High quality China standard light duty steel |
| 28 |
Operation way |
PLC control way |
| 29 |
Loading and discharging way |
Rear overturning mechanism |
| 30 |
Compacted way |
Bi-directional compression |
| 31 |
Wastes compacting density |
≥0.8tons/m3 |
| 32 |
One working circle time for loading and discharging |
≤30s |
| 33 |
Max compressing force |
≥150KN |
| 34 |
Max passing force |
≥180KN |
