HOT SALE!2019s new deisgned Dongfeng diesel compressed docking wastes collecting vehicle, Factory direct sale best price compression docking garbage truck
The technical advantages of nee designed CLW Brand compression docking garbage truck as below
1, the sliding structure of the push plate is with s groove track on both sides; comparing to the track placed on the floor of the truck, this kind of structure with the advantages of high rigidity, good stability, no deformation of the bottom plate, smooth movement of the push plate, clean waste discharge and reliable work, etc.
2,The van box body of the wastes collecting truck is made of high-strength weather-resistant steel, and the whole steel design, the weight of the whole vehicle is light, the garbage load is large, and the fuel is saved, which ensures that the car body is not deformed and has good economy.
3, The optimized design of the medium-pressure transformer hydraulic system has the advantages of fast dynamic response, low heat loss inside the system, high work efficiency, short operation cycle time and simple operation, compared with the high-pressure system with constant pressure throughout the system. Especially reliable work and low failure rate.
4, The design of the central sewage conduit prevents the leakage of sewage and the design of the closed air of the vehicle, completely solving the secondary pollution problems such as running, running, dripping and leaking, thus absolutely avoiding the secondary pollution of the garbage truck during compression loading and transportation.
5, Equipped with an in-cabin operating system for garbage loading, push plate compression and unloading through cab operation.
6, There is a contact buzzer on the front lower side of the cabinet and the cab, through which the operator and the driver can communicate. The “Emergency Stop Device” button next to the tumbling mechanism can stop the operation in time and protect the operator at all times.
If you're really interested in our wastes collecting vehicle, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat: +86 13329899995.
main technical parameters of CLW brand compressed docking garbage truck as below
| Classification |
Item |
Unit |
Parameter |
| Vehicle |
Vehicle model |
|
CLW5070DEAW(hydraulic lifter garbage truck) |
| Manufacturer |
|
ChengLi Special Automobile Co.,Ltd |
| Overall dimensions |
mm |
5790×2100×2280 |
| Curb weight |
kg |
3580 |
| Traction system |
|
4×2 |
| Max speed |
km/h |
90 |
| Chassis |
Chassis model |
|
EQ1072GLJ |
| Manufacturer |
|
Dongfeng Motor Corporation |
| Number of axles |
|
2 |
| Wheel base |
mm |
3300 |
| Tire specification |
|
7.00-16LT 14PR |
| Number of tires |
|
6 |
| F/R track base |
mm |
1070 /1420 |
| Engine |
Engine model |
|
CY4BK251 |
| Manufacturer |
|
Dongfeng chaoyang dynasty chai power co. LTD |
| Fuel type |
|
Diesel |
| Power |
kw |
96 |
| Engine horse power |
hp |
130 |
| Displacement |
ml |
3856 |
| emission standard |
|
Euro V |
| Instruction |
1. Hydraulic lifter garbage truck also named self loading garbage truck
2. Equipped with sealed garbage box , hydraulic system and operating system .
3. Equipped with 2 lift oil cylinders , the trash can be lowered from the crane , the working cycle time ≤ 50S
4. The feature is that the truck can match dozens of trash cans
|
| Remark |
1, Optional cab with chassis
2, Optional the side device of the top
|
| Color &Painting |
According to customer’s requirements |
More pictures of CLW brand compression docking wastes collecting vehicle as below
HOT SALE! DONGFENG hydraulic lifter garbage truck
Customized Dongfeng compression docking wastes collecting vehicle for sale
High quality and competitive price CLW Brand compression docking garbage truck for sale
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of garbage trucks in China since 2004s. With many years' experience in developing, Chengli Special Automobile Co., Ltd. could supply garbage compactor truck, refuse garbage truck, swing arm garbage truck, skid loader garbage truck, side loader garbage truck, sealed garbage truck, dump garbage truck, etc. More information, please feel free to contact Ms. Anita Deng.
