The waste truck compactor is usually called compactor garbage truck,garbage compactor truck, compression garbage truck,garbage compact truck,compressed refuse truck,etc.
Our compactor waste truck for sale is constructed with 12# low alloy steeland 5mm, 4mm, 10mm steel.The body is fitted on the chassis by the truck beam.The body floor is fully sealed.All the sewage can go directly into the sewage tank,so as not to corrode the body and chassis .Moreover,it can also prevent the sewage leakage while the truck is driving on the road and avoid the secondary pollution.
The refuse compactor truck usually compacts the waste using a hydraulically powered mechanism that employs a moving plate or shovel to scoop the waste out from the loading hopper and compress it against a moving wall. In most compactor designs, the plate has a pointed edge (hence giving it the industry standard name packer blade) which is designed to apply point pressure to the waste to break down bulky items in the hopper before being drawn into the main body of the truck.
There are three kinds of mechanism options available to the customer,barrel turnover mechanism,panel turnover mechanism and tipping mechanism.by the use of hydraulics,the barrel is locked during the overturning process,which is very safe and reliable.
As a professional special vehicle manufacturer in China, with ISO9001-2008 quality system and 3C certificate, the waste garbage compactor trucks we produce is from 4m³ to 18m³.
As a professional refuse collection truck manufacturer in China, we have garbage dumper truck, compactor garbage truck, swing arm garbage truck, hook type garbage truck, side self loading garbage truck, etc.
If you're interested in our garbage compactor truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of SINO TRUK HOWO 20cbm garbage compactor truck as below.
Technical Parameters of 6x4 china sinotruk waste truck compactor 20m3 as below
| Items |
Descriptions |
Specifications and Types |
| General |
Truck Name |
Garbage Compactor truck |
| Drive Type |
6*4 |
| Gross Weight(kg) |
25000 |
| Curb Weight (kg) |
15330 |
| Overall Dimensions (mm) |
10315*2500*3400 |
| Engine |
Engine Brand |
SINOTRUK |
| Fuel Type |
Diesel |
| Power |
371HP |
| Emission Standard |
Euro II |
| Displacement(ml) |
9726 |
| Chassis |
Chassis Brand |
HOWO |
| Cab |
Flat roof, one row with single sleeper |
| Wheelbase (mm) |
4300+1400 |
| Axle No. |
3 |
| Tire No. |
10+1 |
| Tire Specification |
295/80R22.5 Tubeless tire |
| Gear Box |
10 speed forward with 1 reverse, manual |
| Steering Wheel |
Left Hand Drive with power-assisted |
| Brake |
Air brake |
| Garbage Container |
Container Volume(m3) |
20 |
| Container Material &Thickness(mm) |
Q345, Side plate 5mm, floor plate 5mm |
| Others |
1. Equipped with completely sealed dustbin, hydraulic system, operation system.
2.Equipped with rear turnover mechanism,can hook dustbin or loading garbage by itself.
3.Equipped screeds and ejection, compress by itself.High compression ratio.
4.The sewage will flow to sewage tank automatically, avoid second pollution.
5.Manual operation level & electric operation button, easily operation,high safety.
|
