ISUZU brand 700P 8cbm garbage compactor truck for sale,
Garbage compactor truck ,also called compactor garbage truck , garbage truck for sale , trash compactor , compression garbage truck , refuse truck , garbage collection vehicle, waste truck container garbage truck, compact garbage trucks, waste compactor trucks, compactor garbage truck for sale etc
Garbage compactor truck capacity from 3 cbm to 18cbm all available .
Chengli brand Garbage compactor truck advantage as below.
1 Dual operation both at the rear of compactor garbage truck and inside cabin , easy control
2 Famous brand hydraulic pump to drive hydraulic valve to keep garbage compactor truck safety
3 Cheap price , one year warranty
4 Garbage bin lifting system could design as customer’s requirement .
5 Lock system is operated by machinery hydraulic system can reduce second pollution mostly.
If you're intereested in our garbage compactor truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
ISUZU 700P garbage compactor truck adopts ISUZU brand 700P single row driver cab, 3815mm wheelbase 4HK1-TCG40 190hp diesel Euro 4 engine, ISUZU MLD 6 speed gearbox, 4tons front axle/7tons rear axle, 8,25-16 nylon tires, oil cut braking with vacuum booster pump, etc.
The volume of ISUZU brand 700P 190hp diesel garbage compactor truck is 8cbm.
More pictures of ISUZU brand 700P 8cbm garbage compactor truck as below.
main technical parameters of ISUZU brand 700P 8cbm garbage compactor truck as below.
| 1 |
Product name |
ISUZU 4*2 LHD 8m3 garbage compactor truck
|
| 2 |
Truck chassis model |
QL11009KARY
|
| 3 |
Overall dimension(L*W*H) |
7365,7105,7225×2250,2200×2830,3085
|
| 4 |
Total mass(kgs) |
10000 |
| 5 |
Curb mass(kgs) |
6620 |
| 6 |
Rated mass(kgs) |
3185 |
| 7 |
Volume |
8m3 |
| 8 |
Real loading capacity |
About 5tons |
| 9 |
Max speed |
95kw/h |
| 10 |
Wheelbase |
3815 |
| 11 |
Axle nos. |
2 |
| 12 |
Driver cab |
ISUZU single row driver cab with 2-3 seats with power steering and air conditioner. |
| 13 |
Approach/departure angle(°) |
21/12 |
| 14 |
Front/rear suspension (mm) |
1110/2440 |
| 15 |
Front/rear tread(mm) |
1680/1650 |
| 16 |
Tire specification |
8.25-16*6 |
| 17 |
Spring |
8/10+6 |
| 18 |
Engine model |
4HK1-TCG40 |
| 19 |
Rated power |
139KW/190hp |
| 20 |
Displacement(ml) |
5193ml |
| 21 |
Fuel type |
Diesel |
| 22 |
Emission standard |
Euro Ⅳ |
| 23 |
Gearbox |
Isuzu MLD 6speed gearbox, manual |
| 24 |
Front/rear axle |
4tons/7tons |
| 25 |
Color |
Different color upon request |
| 26 |
Wastes van |
Solid arc-shape box body of strength beam and steel plate welded |
| 27 |
Wastes van material |
High quality China standard light duty steel |
| 28 |
Operation way |
PLC control way |
| 29 |
Loading and discharging way |
Rear overturning mechanism |
| 30 |
Compacted way |
Bi-directional compression |
| 31 |
Wastes compacting density |
≥0.8tons/m3 |
| 32 |
One working circle time for loading and discharging |
≤30s |
| 33 |
Max compressing force |
≥150KN |
| 34 |
Max passing force |
≥180KN |
