ISUZU brand 4*2 LHD 5cbm 120hp diesel Euro 6 garbage compactor truck for sale, good price ISUZU 3-4tons compacted garbage truck
Garbage compactor truck ,also called compactor garbage truck , garbage truck for sale , trash compactor , compression garbage truck , refuse truck , garbage collection vehicle, waste truck container garbage truck, compact garbage trucks, waste compactor trucks, compactor garbage truck for sale etc
Garbage compactor truck capacity from 3 cbm to 18cbm all available .
Chengli brand Garbage compactor truck advantage as below.
1 Dual operation both at the rear of compactor garbage truck and inside cabin , easy control
2 Famous brand hydraulic pump to drive hydraulic valve to keep garbage compactor truck safety
3 Cheap price , one year warranty
4 Garbage bin lifting system could design as customer’s requirement .
5 Lock system is operated by machinery hydraulic system can reduce second pollution mostly.
ISUZU brand 5cbm garbage truck adopts Isuzu 100P single row driver cab, 3360mm wheelbase, ISUZU 4KH1CN6LB 88KW/120HP diesel Euro 6 engine, ISUZU MSB 5 speed gearbox, 2tons front axle/4tons rear axle, 7.00R16 rail tires, ABS, power steering and air conditioner, etc.
If you're interested in our garbage compactor truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
More pictures of ISUZU brand 5cbm garbage compactor truck as below.
The volume of Isuzu Brand 120hp diesel garbage compactor truck is 5cbm.
The volume of ISUZU brand 600P 5cbm garbage compactor truck as below.
| 1 |
Product name |
ISUZU 4*2 LHD 5m3 garbage compactor truck(100P)
|
| 2 |
Truck chassis model |
QL1070
|
| 3 |
Overall dimension(L*W*H) |
6650×2050×2750
|
| 4 |
Total mass(kgs) |
7300 |
| 5 |
Curb mass(kgs) |
5300 |
| 6 |
Rated mass(kgs) |
1870 |
| 7 |
Volume |
5m3 |
| 8 |
Real loading capacity |
About 3-4tons |
| 9 |
Max speed |
95kw/h |
| 10 |
Wheelbase |
3360 |
| 11 |
Axle nos. |
2 |
| 12 |
Driver cab |
ISUZU 4*2 single row driver cab with 2-3 seats with power steering and air conditioner. |
| 13 |
Approach/departure angle(°) |
24/16 |
| 14 |
Front/rear suspension (mm) |
1015/2045 |
| 15 |
Front/rear tread(mm) |
1504/1425 |
| 16 |
Tire specification |
7.00R16*6 |
| 17 |
Spring |
8/6+5 |
| 18 |
Engine model |
4KH1CN6LB |
| 19 |
Rated power |
88KW/120HP |
| 20 |
Displacement(ml) |
2999ml |
| 21 |
Fuel type |
Diesel |
| 22 |
Emission standard |
Euro 6 |
| 23 |
Gearbox |
ISUZU MSB 5 speed gearbox, manual |
| 24 |
Front/rear axle |
2tons/4tons |
| 25 |
Color |
Different color upon request |
| 26 |
Wastes van |
Solid arc-shape box body of strength beam and steel plate welded |
| 27 |
Wastes van material |
High quality China standard light duty steel |
| 28 |
Operation way |
PLC control way |
| 29 |
Loading and discharging way |
Rear overturning mechanism |
| 30 |
Compacted way |
Bi-directional compression |
| 31 |
Wastes compacting density |
≥0.8tons/m3 |
| 32 |
One working circle time for loading and discharging |
≤30s |
| 33 |
Max compressing force |
≥150KN |
| 34 |
Max passing force |
≥180KN |
