HOT SALE! JMC brand 4*2 LHD kaiyun brand 152hp Euro 6 diesel 7cbm garbage compactor truck, China made wastes collecting vehicle for sale
Customized JMC brand 4*2 LHD kaiyun brand diesel 7cbm garbage compactor truck adopts JMC flathead single row driver cab with air conditioner, and power steering, JX4D306H JIANGLING 112KW/152hp diesel engine, 6 speed gearbox, 7.50R16 rail tires*6,3360mm wheelbase, etc.
The volume of this is JMC brand compressed garbage truck is 7cbm. And with the wastes loading capacity of about 6tons. THe wastes van of CLW Brand compacted garbage truck adopts high quality China standard light duty steel, solid arc-shape box body of strengthen beam and steel plate weled.
Operation way: PLC control system; loading and discharging way: rear loading wastes bins mechanism; compacting way: Bi-directional compression; wastes compacting density≥0.8T/m³; one working circle time for loading and discharging ≤30s; max compressing force≥150KN; max passing force≥180KN.
If you're interested in our compacted garbage truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.:+86 13329899995.
More pictures of JMC brand 152 Euro 6 diesel 7cbm compacted garbage truck manufactured by Chengli Special Automobile Co., Ltd. as below.
main technical parameters of JMC brand 4*2 LHD diesel 7cbm garbage compactor truck manufactured by Chengli Special Automobile Co., Ltd.
| 1 |
Product name |
JMC 4*2 LHD 7m3 garbage compactor truck
|
| 2 |
Truck chassis model |
JX1083TG26
|
| 3 |
Overall dimension(L*W*H) |
6860×2200×2580
|
| 4 |
Total mass(kgs) |
8200 |
| 5 |
Curb mass(kgs) |
6070 |
| 6 |
Rated mass(kgs) |
1935 |
| 7 |
Volume |
7m3 |
| 8 |
Real loading capacity |
About 5-6tons |
| 9 |
Max speed |
80kw/h |
| 10 |
Wheelbase |
3360 |
| 11 |
Axle nos. |
2 |
| 12 |
Driver cab |
JMC flathead single row driver cab with air conditioner |
| 13 |
Approach/departure angle(°) |
20/12 |
| 14 |
Front/rear suspension (mm) |
1125/1995 |
| 15 |
Front/rear tread(mm) |
1580/1530 |
| 16 |
Tire specification |
7.50R16*6 |
| 17 |
Spring |
8/7+7 |
| 18 |
Engine model |
JIANGLING DIESEL ENGINE |
| 19 |
Rated power |
112KW/152hp |
| 20 |
Displacement(ml) |
2892ml |
| 21 |
Fuel type |
Diesel |
| 22 |
Emission standard |
Euro Ⅵ |
| 23 |
Gearbox |
6 speed gearbox, manual |
| 24 |
Axle load(kgs) |
2930/5270 |
| 25 |
Color |
Different color upon request |
| 26 |
Wastes van |
Solid arc-shape box body of strength beam and steel plate welded |
| 27 |
Wastes van material |
High quality China standard light duty steel |
| 28 |
Operation way |
PLC control way |
| 29 |
Loading and discharging way |
Rear overturning mechanism |
| 30 |
Compacted way |
Bi-directional compression |
| 31 |
Wastes compacting density |
≥0.8tons/m3 |
| 32 |
One working circle time for loading and discharging |
≤30s |
| 33 |
Max compressing force |
≥150KN |
| 34 |
Max passing force |
≥180KN |
