Customized dongfeng D9 13cbm 230hp diesel garbage compactor truck for sale,best seller 12cbm compacted garbage truck

Customized dongfeng D9 13cbm 230hp diesel garbage compactor truck for sale,best seller 12cbm compacted garbage truck

    • Customized dongfeng D9 13cbm 230hp diesel garbage compactor truck for sale,best seller 12cbm compacted garbage truck
    • Customized dongfeng D9 13cbm 230hp diesel garbage compactor truck for sale,best seller 12cbm compacted garbage truck
    • Customized dongfeng D9 13cbm 230hp diesel garbage compactor truck for sale,best seller 12cbm compacted garbage truck
    • Customized dongfeng D9 13cbm 230hp diesel garbage compactor truck for sale,best seller 12cbm compacted garbage truck
  • Customized dongfeng D9 13cbm 230hp diesel garbage compactor truck for sale,best seller 12cbm compacted garbage truck

    Product Details:

    Place of Origin: China
    Brand Name: CLW
    Certification: CCC, ISO 9001

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: negotiable
    Packaging Details: in bulk package, waxed
    Delivery Time: 20 days
    Payment Terms: T/T, L/C
    Supply Ability: 20units/month
    Contact Now
    Detailed Product Description
    Color: Different Color Upon Request, Free To Paint Company Logo Truck Chassis: Chinamade Dongfeng D9 LHD 230hp Diesel Truck Chassis
    Price: High Quality Factory Direct Sale Price





    Customized dongfeng D9 4*2 13cbm 230hp diesel garbage compactor truck for sale,best seller new face 12cbm compacted garbage truck for sale



    Customized dongfeng D9 4*2 13cbm 230hp diesel garbage compactor truck for sale adopts dongfeng D9 one row and a half luxurious driver cab, 4500mm wheelbase, 8 speed gearbox, 5tons front axle/10tons rear axle, 10.00R20 rail tires*6, B6.2NS6B230 Cummins 230hp diesel engine, etc.



    The volume of dongfeng D9 compression garbage truck is 12cbm-13cbm.



    main technical parameters of dongfeng D9 13cbm garbage compactor truck manufactured by Chengli Special Automobile Co., Ltd. as below.

    1 Product name

    Dongfeng 4*2 LHD 13m3 garbage compactor truck (CLW5180ZYS6)

    2 Truck chassis model

    EQ1185

    3 Overall dimension(L*W*H)

    8350×2550×3300

    4 Total mass(kgs) 18000
    5 Curb mass(kgs) 9700
    6 Rated mass(kgs) 8170
    7 Volume 13m3
    8 Max speed 105kw/h
    9 Wheelbase 4500
    10 Axle nos. 3
    11 Driver cab dongfeng D9 one row and a half luxurious driver cab
    12 Approach/departure angle(°) 19/12
    13 Front/rear suspension (mm) 1260/2390
    14 Front/rear tread(mm) 1862/1800
    15 Tire specification 10.00R20*10+1
    16 Steel Spring 8/10+7
    17 Engine model B6.2NS6B230
    18 Rated power 169KW/230hp
    19 Displacement(ml) 6200ml
    20 Fuel type Diesel
    21 Emission standard Euro Ⅵ
    22 Gearbox 8 speed gearbox, manual
    23 Front/rear axle 5tons front axle/10tons double rear axles
    24 Color Different color upon request
    25 Wastes van Solid arc-shape box body of strength beam and steel plate welded
    26 Wastes van material High quality China standard light duty steel
    27 Operation way PLC control way
    28 Loading and discharging way Rear overturning mechanism
    29 Compacted way Bi-directional compression
    30 Wastes compacting density ≥0.8tons/m3
    31 One working circle time for loading and discharging ≤30s
    32 Color White color upon request

    If you're interested in our garbage compactor truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995



    More pictures of new designed dongfeng D9 13cbm compacted garbage truck as below.

    Customized dongfeng D9 13cbm 230hp diesel garbage compactor truck for sale,best seller 12cbm compacted garbage truck

    Customized dongfeng D9 13cbm 230hp diesel garbage compactor truck for sale,best seller 12cbm compacted garbage truck

    Customized dongfeng D9 13cbm 230hp diesel garbage compactor truck for sale,best seller 12cbm compacted garbage truck

    s a professional compactor refuse truck manufacturer in China, we have dumper garbage truck, refuse compactor garbage truck, arm roll garbage truck, hook lifter waste truck, side self-loading garbage truck, etc.


    The refuse compactor truck is usually called compactor garbage truck,garbage compactor truck, compacted garbage truck,compressed refuse truck, waste compactor truck, etc.



    Our trash truck compactor is constructed with 12# low alloy steeland 5mm, 4mm, 10mm steel.The body is fitted on the chassis by the truck beam.The body floor is fully sealed.All the sewage can go directly into the sewage tank,so as not to corrode the body and chassis .Moreover,it can also prevent the sewage leakage while the truck is driving on the road and avoid the secondary pollution.



    The refuse compactor truck for sale usually compacts the waste using a hydraulically powered mechanism that employs a moving plate or shovel to scoop the waste out from the loading hopper and compress it against a moving wall. In most compactor designs, the plate has a pointed edge (hence giving it the industry standard name packer blade) which is designed to apply point pressure to the waste to break down bulky items in the hopper before being drawn into the main body of the truck.



    There are three kinds of mechanism options available to the customer,barrel turnover mechanism,panel turnover mechanism and tipping mechanism.by the use of hydraulics,the barrel is locked during the overturning process,which is very safe and reliable.



    As a professional compression garbage truck manufacturer in China, with ISO9001-2008 quality system and 3C certificate, the trash compactor trucks we produce is from 4m³ to 18m³. The mini trash compactor for sale is 4 cubic meters.
