Dongfeng 4*2 LHD 140HP Euro 6 4cbm garbage compactor truck for sale, wastes collecting vehicle supplier for sale
Customized dongfeng 4*2 LHD 4cbm diesel garbage compactor truck, adopts DONGFENG 1730mm single row driver cab with air conditioner, 3308mm wheelbase, YC4Y24140-60 140hp YUCHAI Euro Ⅵ diesel engine 5 speed gearbox, 7.00R16 rail tires*6, 5.5tons front axle, etc.
The volume of dongfeng brand 4*2 LHD 4cbm garbage compacted truck is 4cbm.
If you're interested in our garbage compactor truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of Dongfeng 4*2 LHD 4CBM compacted garbage truck as below.
Main technical parameters of dongfeng 4*2 LHD 140hp diesel garbage compactor truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| 1 |
Product name |
Dongfeng 4*2 LHD 4m3 garbage compactor truck
|
| 2 |
Truck chassis model |
EQ1075
|
| 3 |
Overall dimension(L*W*H) |
6840×1940×2370
|
| 4 |
Total mass(kgs) |
7360 |
| 5 |
Curb mass(kgs) |
5340,4930 |
| 6 |
Rated mass(kgs) |
1890 |
| 7 |
Volume |
4m3 |
| 8 |
Real loading capacity |
About 3tons |
| 9 |
Max speed |
110kw/h |
| 10 |
Wheelbase |
3308 |
| 11 |
Axle nos. |
2 |
| 12 |
Driver cab |
DONGFENG 1730mm single row driver cab with air conditioner, |
| 13 |
Approach/departure angle(°) |
27.7/14 |
| 14 |
Front/rear suspension (mm) |
1055/1937 |
| 15 |
Front/rear tread(mm) |
1613/1760 |
| 16 |
Tire specification |
7.00R16*6 |
| 17 |
Spring |
3/3+3 |
| 18 |
Engine model |
YC4Y24140-60 |
| 19 |
Rated power |
103KW/140hp |
| 20 |
Displacement(ml) |
2360ml |
| 21 |
Fuel type |
Diesel |
| 22 |
Emission standard |
Euro Ⅵ |
| 23 |
Gearbox |
5 speed gearbox, manual |
| 24 |
Axle load(kgs) |
2640/4720 |
| 25 |
Color |
Different color upon request |
| 26 |
Wastes van |
Solid arc-shape box body of strength beam and steel plate welded |
| 27 |
Wastes van material |
High quality China standard light duty steel |
| 28 |
Operation way |
PLC control way |
| 29 |
Loading and discharging way |
Rear overturning mechanism |
| 30 |
Compacted way |
Bi-directional compression |
| 31 |
Wastes compacting density |
≥0.8tons/m3 |
| 32 |
One working circle time for loading and discharging |
≤30s |
CLW brand compactor garbage truck is constructed with 12# low alloy steeland 5mm, 4mm, 10mm steel.The body is fitted on the chassis by the truck beam.The body floor is fully sealed.All the sewage can go directly into the sewage tank,so as not to corrode the body and chassis .Moreover,it can also prevent the sewage leakage while the truck is driving on the road and avoid the secondary pollution.
The waste compression truck usually compacts the waste using a hydraulically powered mechanism that employs a moving plate or shovel to scoop the waste out from the loading hopper and compress it against a moving wall. In most compactor designs, the plate has a pointed edge (hence giving it the industry standard name packer blade) which is designed to apply point pressure to the waste to break down bulky items in the hopper before being drawn into the main body of the truck.
There are three kinds of mechanism options available to the customer,barrel turnover mechanism,panel turnover mechanism and tipping mechanism.by the use of hydraulics,the barrel is locked during the overturning process,which is very safe and reliable.
Garbage trucks are widely used in sanitation, municipal, factory and mining enterprises, and residential areas where have a lot of garbage. Garbage trucks are classified into compressed garbage trucks, swing arm type, dump type, sealed type, docking type, hook type arm type, and pull arm type garbage truck. Garbage trucks can carry multiple compartments in one vehicle, which can effectively prevent secondary pollution during the loading and unloading process. The modified part is separable from the original car chassis, which is easy to maintain and maintain the mobility and driving performance of the original car. Customers who have special requirements for garbage trucks please contact with us at any time. We can produce the trucks according to your requirements.
