Best seller-dongfeng 165hp diesel Euro 6 7cbm compacted garbage truck for sale, HOT SALE! good price 7cbm garbage compactor truck
Garbage trucks are widely used in sanitation, municipal, factory and mining enterprises, and residential areas where have a lot of garbage. Garbage trucks are classified into compressed garbage trucks, swing arm type, dump type, sealed type, docking type, hook type arm type, and pull arm type garbage truck. Garbage trucks can carry multiple compartments in one vehicle, which can effectively prevent secondary pollution during the loading and unloading process. The modified part is separable from the original car chassis, which is easy to maintain and maintain the mobility and driving performance of the original car. Customers who have special requirements for garbage trucks please contact with us at any time. We can produce the trucks according to your requirements.
The waste compression truck usually compacts the waste using a hydraulically powered mechanism that employs a moving plate or shovel to scoop the waste out from the loading hopper and compress it against a moving wall. In most compactor designs, the plate has a pointed edge (hence giving it the industry standard name packer blade) which is designed to apply point pressure to the waste to break down bulky items in the hopper before being drawn into the main body of the truck.
There are three kinds of mechanism options available to the customer,barrel turnover mechanism,panel turnover mechanism and tipping mechanism.by the use of hydraulics,the barrel is locked during the overturning process,which is very safe and reliable.
If you're interested in our garbage truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Dongfeng 4*2 LHD 165hp 7cbm compacted garbage truck, adopts dongfeng DUOLIKA 2030mm single row driver cab with air conditioner, YCY30165-60 165hp Euro 6 diesel engine, 7.50R16 rail tires*6, 5.5tons front axle, 3800mm wheelbase, 6 speed gearbox, ABS, etc.
The volume of dongfeng duolika garbage compactor truck is 7cbm.
More pictures of dongfeng 7cbm garbage compactor truck manufactured by Chengli Special Automobile Co., Ltd. as below.
Customized dongfeng7CBM garbage compactor truck for sale,
| 1 |
Product name |
Dongfeng 4*2 LHD 7m3 garbage compactor truck
|
| 2 |
Truck chassis model |
EQ1095
|
| 3 |
Overall dimension(L*W*H) |
7340×2350×2800
|
| 4 |
Total mass(kgs) |
9100 |
| 5 |
Curb mass(kgs) |
6500 |
| 6 |
Rated mass(kgs) |
2405 |
| 7 |
Volume |
7m3 |
| 8 |
Real loading capacity |
About 5-6tons |
| 9 |
Max speed |
103kw/h |
| 10 |
Wheelbase |
3800 |
| 11 |
Axle nos. |
2 |
| 12 |
Driver cab |
dongfeng DUOLIKA 2030mm single row driver cab with air conditioner |
| 13 |
Approach/departure angle(°) |
21/12 |
| 14 |
Front/rear suspension (mm) |
1130/2160 |
| 15 |
Front/rear tread(mm) |
1745/1800 |
| 16 |
Tire specification |
7.50R16*6 |
| 17 |
Steel Spring |
3/8+6 |
| 18 |
Engine model |
YCY30165-60 |
| 19 |
Rated power |
121KW/165hp |
| 20 |
Displacement(ml) |
2970ml |
| 21 |
Fuel type |
Diesel |
| 22 |
Emission standard |
Euro 6 |
| 23 |
Gearbox |
6 speed gearbox, manual |
| 24 |
Axle load |
3300/5800 |
| 25 |
Color |
Different color upon request |
| 26 |
Wastes van |
Solid arc-shape box body of strength beam and steel plate welded |
| 27 |
Wastes van material |
High quality China standard light duty steel |
| 28 |
Operation way |
PLC control way |
| 29 |
Loading and discharging way |
Rear overturning mechanism |
| 30 |
Compacted way |
Bi-directional compression |
| 31 |
Wastes compacting density |
≥0.8tons/m3 |
| 32 |
One working circle time for loading and discharging |
≤30s |
