HOT SALE! JMC brand kaiyun 4*2 LHD 7CBM garbage compactor truck, 5tons compacted garbage collecting vehicle for sale
Customized JMC brand 4*2 LHD 7cbm compacted garbage truck, adopts high quality JMC kaiyun N800 single row driver cab with power steering and air conditioner, 3360mm wheelbase, 7.50R16 rail tires, 6 speed gearbox, JX4D306H 152hp diesel Euro Ⅵ engine, etc.
The volume of JMC brand compressed garbage truck is 7cbm, with the wastes loading capacity of about 6tons. THe wastes van of CLW Brand compacted garbage truck adopts high quality China standard light duty steel, solid arc-shape box body of strengthen beam and steel plate welded.
Operation way: PLC control system; loading and discharging way: rear loading wastes bins mechanism; compacting way: Bi-directional compression; wastes compacting density≥0.8T/m³; one working circle time for loading and discharging ≤30s; max compressing force≥150KN; max passing force≥180KN.
More pictures of JMC brand 7cbm compacted garbage truck manufactured by Chengli Special Automobile Co., Ltd. as below.
high quality and bestp rice JMC brand 7cbm refuse garbage truck for sale
If you're interested in our garbage compactor truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.:+86 13329899995.
The specification of JMC brand 7CBM garbage compactor truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| 1 |
Product name |
Jmc 4*2 LHD 7m3 garbage compactor truck
|
| 2 |
Truck chassis model |
JX1083
|
| 3 |
Overall dimension(L*W*H) |
6860×2200×2580
|
| 4 |
Total mass(kgs) |
8200 |
| 5 |
Curb mass(kgs) |
6070 |
| 6 |
Driver cab person |
3 included the driver |
| 7 |
Volume |
7m3 |
| 8 |
Real loading capacity |
About 5ons |
| 9 |
Max speed |
80kw/h |
| 10 |
Wheelbase |
3360 |
| 11 |
Axle nos. |
2 |
| 12 |
Driver cab |
JMC kaiyun N800 single row driver cab with power steering and air conditioner |
| 13 |
Approach/departure angle(°) |
20/12 |
| 14 |
Front/rear suspension (mm) |
1125/1995 |
| 15 |
Front/rear tread(mm) |
1580/1530 |
| 16 |
Tire specification |
7.50R16 |
| 17 |
Spring |
8/7+7 |
| 18 |
Engine model |
JX4D306H |
| 19 |
Rated power |
112KW/152hp |
| 20 |
Displacement(ml) |
3856ml |
| 21 |
Fuel type |
Diesel |
| 22 |
Emission standard |
Euro Ⅵ |
| 23 |
Gearbox |
6 speed gearbox, manual |
| 24 |
Axle load(kgs) |
2930/5270 |
| 25 |
Color |
Different color upon request |
| 26 |
Wastes van |
Solid arc-shape box body of strength beam and steel plate welded |
| 27 |
Wastes van material |
High quality China standard light duty steel |
| 28 |
Operation way |
PLC control way |
| 29 |
Loading and discharging way |
Rear overturning mechanism |
| 30 |
Compacted way |
Bi-directional compression |
| 31 |
Wastes compacting density |
≥0.8tons/m3 |
| 32 |
One working circle time for loading and discharging |
≤30s |
| 33 |
Max compressing force |
≥150KN |
| 34 |
Max passing force |
≥180KN |
