HOT SALE!JAC Junling V7 120KW diesel 8cbm garbage compactor truck, refuse garbage truck supplier in China
Chengli brand Garbage compactor truck advantage as below.
1 Dual operation both at the rear of compactor garbage truck and inside cabin , easy control
2 Famous brand hydraulic pump to drive hydraulic valve to keep garbage compactor truck safety
3 Cheap price , one year warranty
4 Garbage bin lifting system could design as customer’s requirement .
5 Lock system is operated by machinery hydraulic system can reduce second pollution mostly.
Garbage truck is also called compact garbage truck,compactor garbage truck,compression garbage truck,garbage compactor,etc.
The waste compression truck usually compacts the waste using a hydraulically powered mechanism that employs a moving plate or shovel to scoop the waste out from the loading hopper and compress it against a moving wall. In most compactor designs, the plate has a pointed edge (hence giving it the industry standard name packer blade) which is designed to apply point pressure to the waste to break down bulky items in the hopper before being drawn into the main body of the truck.
And with the wastes loading capacity of about 6tons. THe wastes van of CLW Brand compacted garbage truck adopts high quality China standard light duty steel, solid arc-shape box body of strengthen beam and steel plate weled.
Operation way: PLC control system; loading and discharging way: rear loading wastes bins mechanism; compacting way: Bi-directional compression; wastes compacting density≥0.8T/m³; one working circle time for loading and discharging ≤30s; max compressing force≥150KN; max passing force≥180KN.
If you're interested in our garbage compactor truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
HOT SALE!JAC Junling V7 8cbm garbage compactor truck for sale
Customized JAC brand 8cbm garbage compactor truck, adopts JAC JUNLING V7 2071 width driver cab with air conditioner and power steering, 3845mm wheelbase, 3tons front axle/7.2tons rear axle, 6 speed gearbox, 3845mm wheelbase, 245/70R19.5 14PR tires, etc.
The volume of JAC JUNLING garbage compactor truck is 8cbm. And with the wastes loading capacity of about 6tons. THe wastes van of CLW Brand compacted garbage truck adopts high quality China standard light duty steel, solid arc-shape box body of strengthen beam and steel plate weled.
Operation way: PLC control system; loading and discharging way: rear loading wastes bins mechanism; compacting way: Bi-directional compression; wastes compacting density≥0.8T/m³; one working circle time for loading and discharging ≤30s; max compressing force≥150KN; max passing force≥180KN.
More pictures of JAC brand 4*2 LHD 8CBM diesel compacted garbage truck manufactured by Chengli Special Automobile Co., Ltd. as below.
HOT SALE! JAC brand 4*2 120KW diesel 8cbm compacted garbage truck for sale
Main technical parameters of JAC Brand 4*2 LHD 8cbm garbage compactor truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| 1 |
Product name |
JAC brand 4*2 LHD 8m3 garbage compactor truck for sale
|
| 2 |
Truck chassis model |
HFC1121
|
| 3 |
Overall dimension(L*W*H) |
7450,7700×2400×2800
|
| 4 |
Total mass(kgs) |
11920 |
| 5 |
Curb mass(kgs) |
6700,6750,7050 |
| 6 |
Driver cab person |
3 included the driver |
| 7 |
Volume |
8m3 |
| 8 |
Real loading capacity |
About 5-6tons |
| 9 |
Max speed |
100kw/h |
| 10 |
Wheelbase |
3845 |
| 11 |
Axle nos. |
2 |
| 12 |
Driver cab |
JAC JUNLING V7 2071 width driver cab |
| 13 |
Approach/departure angle(°) |
20/12,20/11 |
| 14 |
Front/rear suspension (mm) |
1075/2130,1075/2380 |
| 15 |
Front/rear tread(mm) |
1705/1805 |
| 16 |
Tire specification |
245/70R19.5 14PR |
| 17 |
Spring |
9/9+7 |
| 18 |
Engine model |
D30TCIF2 |
| 19 |
Rated power |
120KW/163hp |
| 20 |
Displacement(ml) |
2977ml |
| 21 |
Fuel type |
Diesel |
| 22 |
Emission standard |
Euro Ⅵ |
| 23 |
Gearbox |
6 speed gearbox, manual |
| 24 |
Front/rear axle |
3tons/7.2tons |
| 25 |
Color |
Different color upon request |
| 26 |
Wastes van |
Solid arc-shape box body of strength beam and steel plate welded |
| 27 |
Wastes van material |
High quality China standard light duty steel |
| 28 |
Operation way |
PLC control way |
| 29 |
Loading and discharging way |
Rear overturning mechanism |
| 30 |
Compacted way |
Bi-directional compression |
| 31 |
Wastes compacting density |
≥0.8tons/m3 |
| 32 |
One working circle time for loading and discharging |
≤30s |
| 33 |
Max compressing force |
≥150KN |
| 34 |
Max passing force |
≥180KN |
