Dongfeng 6*4 LHD T5 260hp diesel Euro 6 18cbm garbage compactor truck for sale, HOT SALE! 18cbm refuse garbage compactor truck
Garbage compactor truck ,also called compactor garbage truck , garbage truck for sale , trash compactor , compression garbage truck , refuse truck , garbage collection vehicle, waste truck container garbage truck, compact garbage trucks, waste compactor trucks, compactor garbage truck for sale etc
Garbage compactor truck capacity from 3 cbm to 18cbm all available .
Chengli brand Garbage compactor truck advantage as below.
1 Dual operation both at the rear of compactor garbage truck and inside cabin , easy control
2 Famous brand hydraulic pump to drive hydraulic valve to keep garbage compactor truck safety
3 Cheap price , one year warranty
4 Garbage bin lifting system could design as customer’s requirement .
5 Lock system is operated by machinery hydraulic system can reduce second pollution mostly.
Our trash truck compactor is constructed with 12# low alloy steeland 5mm, 4mm, 10mm steel.The body is fitted on the chassis by the truck beam.The body floor is fully sealed.All the sewage can go directly into the sewage tank,so as not to corrode the body and chassis .Moreover,it can also prevent the sewage leakage while the truck is driving on the road and avoid the secondary pollution.
The refuse compactor truck for sale usually compacts the waste using a hydraulically powered mechanism that employs a moving plate or shovel to scoop the waste out from the loading hopper and compress it against a moving wall. In most compactor designs, the plate has a pointed edge (hence giving it the industry standard name packer blade) which is designed to apply point pressure to the waste to break down bulky items in the hopper before being drawn into the main body of the truck.
There are three kinds of mechanism options available to the customer,barrel turnover mechanism,panel turnover mechanism and tipping mechanism.by the use of hydraulics,the barrel is locked during the overturning process,which is very safe and reliable.
As a professional compression garbage truck manufacturer in China, with ISO9001-2008 quality system and 3C certificate, the trash compactor trucks we produce is from 4m³ to 18m³. The mini trash compactor for sale is 4 cubic meters.
If you're interested in our compacted garbage truck, please send email to truck0011@163.com or talk to Anita by
Whatsapp/Wechat/MOb.: +86 13329899995.
HOT SALE!DONGFENG T5 diesel 18cbm compacted garbage truck, adopts Dongfeng T5 one row and a half driver cab with air condtioner, 5tons front axle/10tons rear axles, 11.00R20 rail tires, 4350+1350mm wheelbase, fastgear 8JS118 8 speed gearbox, B6.2NS6B260 Cummins 260hp diesel Euro 6 engine, power steering, etc.
The volume of dongfeng T5 6*4 LHD garbage compactor truck is 18CBM.
More pictures of Dongfeng T5 18cbm compacted garbage truck manufactured by Chengli Special Automobile Co., Ltd. as below.
HOT SALE! dongfeng T5 18cbm refuse garbage truck for sale
main technical parameters of dongfeng T5 18cbm refuse garbage truck as below.
| 1 |
Product name |
Dongfeng 6*4 LHD 18m3 garbage compactor truck (CL5250ZYS6HQ)
|
| 2 |
Truck chassis model |
EQ1250GL6DJ
|
| 3 |
Overall dimension(L*W*H) |
10500×2550×3300
|
| 4 |
Total mass(kgs) |
25000 |
| 5 |
Curb mass(kgs) |
14700 |
| 6 |
Rated mass(kgs) |
10105 |
| 7 |
Volume |
16m3 |
| 8 |
Max speed |
88kw/h |
| 9 |
Wheelbase |
4350+1350 |
| 10 |
Axle nos. |
3 |
| 11 |
Driver cab |
Dongfeng T5 one row and a half driver cab with air condtioner |
| 12 |
Approach/departure angle(°) |
28/12 |
| 13 |
Front/rear suspension (mm) |
1250/3020 |
| 14 |
Front/rear tread(mm) |
1910;1820/1820 |
| 15 |
Tire specification |
11.00R20*10+1 |
| 16 |
Spring |
9/13 |
| 17 |
Engine model |
B6.2NS6B260 |
| 18 |
Rated power |
191KW/260hp |
| 19 |
Displacement(ml) |
6200ml |
| 20 |
Fuel type |
Diesel |
| 21 |
Emission standard |
Euro 3 |
| 22 |
Gearbox |
8 speed gearbox, manual |
| 23 |
Front/rear axle |
5tons front axle/10tons double rear axles |
| 24 |
Color |
Different color upon request |
| 25 |
Wastes van |
Solid arc-shape box body of strength beam and steel plate welded |
| 26 |
Wastes van material |
High quality China standard light duty steel |
| 27 |
Operation way |
PLC control way |
| 28 |
Loading and discharging way |
Rear overturning mechanism |
| 29 |
Compacted way |
Bi-directional compression |
| 30 |
Wastes compacting density |
≥0.8tons/m3 |
| 31 |
One working circle time for loading and discharging |
≤30s |
| 32 |
Color |
White color upon request |
