HOT SALE! Customized 10cbm 8tons compacted garbage trucks for Pakistan, New cheaper price Wastes collecting vehicle for sale
The volume of the compactor garbage van is 10m3,and with the wastes loading capacity of about 7-8tons. THe wastes van of CLW Brand compacted garbage truck adopts high quality China standard light duty steel, solid arc-shape box body of strengthen beam and steel plate weled.
Operation way: PLC control system; loading and discharging way: rear loading wastes bins mechanism; compacting way: Bi-directional compression; wastes compacting density≥0.8T/m³; one working circle time for loading and discharging ≤30s; max compressing force≥150KN; max passing force≥180KN.
If you're interested in our garbage compactor truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of CLW Brand 10cbm garbage compactor truck manufactured by Chengli Special Automobile Co., Ltd. as below.
Customized dongfeng 10cbm garbage compactor truck for sale
factory sale best price wastes collecting vehicle for sale
1 Product name Dongfeng 4*2 LHD 10m3 garbage compactor truck for sale
2 Truck chassis model EQ1110
3 Overall dimension(L*W*H) 7600*2495*3350
4 Total mass(kgs) 11495
5 Curb mass(kgs) 8500
6 Rated mass(kgs) 3950
7 Volume 10m3
8 Real loading capacity About 8-9tons
9 Max speed 90kw/h
10 Wheelbase 3950
11 Axle nos. 2
12 Driver cab Dongfeng 4*2 D913 single row driver cab with 2-3 seats with power steering and without air conditioner. Air conditioner is selective
13 Approach/departure angle(°) 33/11
14 Front/rear suspension (mm) 1250/2550
15 Front/rear tread(mm) 1900/1800
16 Tire specification 9.00-20*6
17 Spring 8/11+8
18 Engine model B170 33
19 Rated power 125KW/170hp
20 Displacement(ml) 5900ml
21 Fuel type Diesel
22 Emission standard Euro 3
23 Gearbox 6/8 speed gearbox, manual
24 Front/rear axle 2.7tons/7.2tons
25 Color Different color upon request
26 Wastes van Solid arc-shape box body of strength beam and steel plate welded
27 Wastes van material High quality China standard light duty steel
28 Operation way PLC control way
29 Loading and discharging way Rear overturning mechanism
30 Compacted way Bi-directional compression
31 Wastes compacting density ≥0.8tons/m3
32 One working circle time for loading and discharging ≤30s
CLW Brand garbage compactor trucks are also called rear loader garbage truck, wastes collecting vehicles, etc. This kind of garbage truck is a kind of special purpose vehicle, mainly used for collecting, transporting and discharging bagged wastes, barreled wastes, bulk household wastes in towns and cities, etc.The wastes is pressured and pushed into the wastes van by the truck mounted wastes propeller (also called negative pressure mechanism), so that making the wastes distributing into the tank evenly and higher density and till full.The collecting and transporting way of the garbage compactor truck adopts widely all over the world. The function of the entire special device adopts the truck engine as power, realizing by hydraulic mechanism manual or electronic control.The wastes van and the loader, which is also called wastes tan and sewer tank, adopting high quality carbon steel with full-sealed welding structure, with the advantages of high strength, light weight, non second pollution, etc. More information, please contact with Ms. Anita.
