Customized SINO TRUK HOWO 266hp diesel 10,000L fresh milk tanker vehicle for sale, stainless steel liquid food beer transported truck for sale
Truck name: SINO TRUK HOWO fresh milk tanker truck for sale
wheelbase: 4600mm
Engine model: WD615.62 266hp diesel Euro 2 diesel engine
Engine rated power: 140kw
gearbox: HW13710 10 speed gearbox, manual
Front axle:HF7
Rear axle: ST16
Overall dimension(L*W*H): 8490×2500×3200
Compartments: 3 compartments
Tanker volume: 10,000Liters
Standard devices of SINO TRUK HOWO 4*2 LHD 10,000L milk tanker truck as below.
1, High quality foodgrade 304-2B 3mm thickness stainless steel plate
2, three compartment; evry compartment is with one self-discharging outlet
3, Every compartment is only with single one PIC cleaning device
4, the temperature will be changed less than 1 degree within 24 hours
5, Insulated layer is with 80mm thickness PU foam
If you're interested in our milk tanker truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of SINO TRUK HOWO 10CBM milk tanker truck as below.
Main technical parameters of SINO TRUK HOWO 4*2 LHD 266hp diesel 10cbm milk tanker truck as below.
| Item |
Descriptions |
Specifications and types |
| General |
Truck name |
SINO TRUK HOWO 4*2 LHD 10cbm Milk tank truck(10,000L) |
| Driving type |
4*2 LHD |
| Total mass(kgs) |
16000 |
| Curb mass(kgs) |
8450kgs |
| Overall dimension(L*W*H)(mm) |
8490×2500×3200 |
| Chassis |
Chassis model |
ZZ1167 |
| Tire specification |
295/80R22.5*6+1 |
| Wheelbase(mm) |
4600 |
| Gearbox |
HW13710 10 speed gearbox, manual |
| Power steering |
Yes |
| Air cut braking |
Yes |
| Engine |
engine model |
WD615.62 |
| Engine brand |
Zhongqi |
| Engine rated power |
266hp |
| Emission standard |
Euro 2 |
| Tanker |
Tanker volume (Liters) |
10,000 |
| Tanker wall material |
High quality foodgrade 304-2B 4mm thickness stainless steel plate |
| Compartment |
single compartments with one self-discharging outlet |
| PIC cleaning device |
three compartments; every compartment is only with single one PIC cleaning device |
| Heat preservation function |
the temperature will be changed less than 1 degree within 24 hours |
| Insulated layer material |
Insulated layer is with 80mm thickness PU foam |
The milk transporter is also called fresh milk transporter, milk tanker, liquid food transporter. The tank body is made of food grade stainless steel plate. The outer part of the tank body needs to be used as insulation layer to prevent the deterioration of fresh milk. The inside of the tank body needs smooth and no acute angle. A CIP (cleaning device) is added to each milk tank.
The material of the tank is made of high-quality aluminum alloy and stainless steel. The tank and the tank are finely polished. The tank can be equipped with heat preservation and refrigeration functions. It can transport a variety of chemical raw materials, dairy products, oil products and liquid food transportation.
The tank can be set to multiple positions according to the demand, and a variety of media can be dispensed at any time, so that the pump can be pumped in and out, and the table can be over-extended, but the table and the self-flowing table can be used.
Fresh milk transport vehicle modification configuration: the tank structure is divided into three layers: insulation layer, insulation layer and tank body.
One. The body of the frame can be made of food grade 304 material stainless steel plate, and the tank body can be made into 2-3 cabins. The tank body requires smooth and no acute angle. A cip (cleaning device) tank is provided in each milk tank with a washer.
Second, the middle of the tank is an insulation layer, which has a heat preservation effect to prevent deterioration of fresh milk. The temperature change does not exceed 1 degree for 24 hours at a temperature difference of 30 degrees. The insulation material is insulated with 80 (mm) thick polyurethane foam material.
Third, the outer layer of the tank (protective layer of the insulation layer) is made of 2mm thick 304L stainless steel. The outer skin and trunk of stainless steel are beautiful in appearance, the whole body is beautiful in appearance, scientific in structure, light in weight and good in strength.
4. Each single warehouse has a separate discharge port (self-flow port) and a feed port (can port).
5. Optional chiller, rock wool insulation, exhaust gas circulation heating, and stainless steel pump to make the vehicle have a suction function.
