Compressed garbage truck is also called Compression garbage truck, compactor garbage truck,Waste Compactors truck.Compactor garbage truck consists of a sealed garbage compartment, hydraulic system, and operating system.Compression type garbage truck can realize garbage collection and transportation capacity reduction, sealing, no secondary pollution, reduce the labor intensity of sanitation workers, improve labor efficiency and other needs. It is widely used in collection, compression and transit garbage which come from cities, towns, rural areas, large factories and mining enterprises and living areas of colleges and universities.
1.High Quality Factory,famous professional and biggest garbage trucks manufacturer direct sale Compressed garbage truck in China;
2.Compactor garbage truck consists of a sealed garbage compartment, hydraulic system, and operating system;
3.High compression ability, huge loading quantity Compressed garbage truck.
4.Automatic design, saving labor, energy conservation and environment protection Compressed garbage truck.
If you're interested in our garbage compactor truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Morepictures of dongfeng tianjin 210hp 20cbm garbage compactor truck manufactured by Chengli Special Automobile Co., Ltd. is as below.
Dongfeng tianjin 6*4 210hp diesel 20cbm garbage compactor truck for sale
| 1 |
Product name |
Dongfeng 6*4 LHD 20m3 garbage compactor truck (CLW5250ZYSD3) |
| 2 |
Truck chassis model |
DEL1250 |
| 3 |
Overall dimension(L*W*H) |
10500×2500×3400 |
| 4 |
Total mass(kgs) |
25000 |
| 5 |
Curb mass(kgs) |
14870 |
| 6 |
Rated mass(kgs) |
10000,9935 |
| 7 |
Volume |
16m3/18m3/20m3 |
| 8 |
Max speed |
90kw/h |
| 9 |
Wheelbase |
4350+1300 |
| 10 |
Axle nos. |
3 |
| 11 |
Driver cab |
Dongfeng 6*4 LHD one row and a half driver cab with power steering and air cut braking and air conditioner |
| 12 |
Approach/departure angle(°) |
20/12 |
| 13 |
Front/rear suspension (mm) |
1460/3340 |
| 14 |
Front/rear tread(mm) |
1986;1860/1860 |
| 15 |
Tire specification |
10.00R20*10+1 |
| 16 |
Spring |
8/9 |
| 17 |
Engine model |
B210 33 |
| 18 |
Rated power |
155KW/210hp |
| 19 |
Displacement(ml) |
5900ml |
| 20 |
Fuel type |
Diesel |
| 21 |
Emission standard |
Euro 3 |
| 22 |
Gearbox |
Bigger 8 speed gearbox, manual |
| 23 |
Front/rear axle |
5tons front axle/10tons double rear axles |
| 24 |
Color |
Different color upon request |
| 25 |
Wastes van |
Solid arc-shape box body of strength beam and steel plate welded |
| 26 |
Wastes van material |
High quality China standard light duty steel |
| 27 |
Operation way |
PLC control way |
| 28 |
Loading and discharging way |
Rear overturning mechanism |
| 29 |
Compacted way |
Bi-directional compression |
| 30 |
Wastes compacting density |
≥0.8tons/m3 |
| 31 |
One working circle time for loading and discharging |
≤30s |
| 32 |
Color |
White color upon request |
| Remark |
If you’re interested in our garbage compactor truck, please send email to truck0011@163.com or whatsapp/Wechat/Mob.: +86 13329899995 |
CLW Brand garbage compactor trucks are also called rear loader garbage truck, wastes collecting vehicles, etc. This kind of garbage truck is a kind of special purpose vehicle, mainly used for collecting, transporting and discharging bagged wastes, barreled wastes, bulk household wastes in towns and cities, etc.The wastes is pressured and pushed into the wastes van by the truck mounted wastes propeller (also called negative pressure mechanism), so that making the wastes distributing into the tank evenly and higher density and till full.The collecting and transporting way of the garbage compactor truck adopts widely all over the world. The function of the entire special device adopts the truck engine as power, realizing by hydraulic mechanism manual or electronic control.The wastes van and the loader, which is also called wastes tan and sewer tank, adopting high quality carbon steel with full-sealed welding structure, with the advantages of high strength, light weight, non second pollution, etc. More information, please contact with Ms. Anita.
