HOT SALE! New designed 33T stainless steel fresh milk tanker semitrailer, Cheaper price liquid food transported tanker for sale
The milk tanker truck is also called fresh milk transporter, milk tanker, liquid food transporter, mobile liquid food transported vehicle. The tank body is made of food grade stainless steel plate. The outer part of the tank body needs to be used as insulation layer to prevent the deterioration of fresh milk. The inside of the tank body needs smooth and no acute angle. A CIP (cleaning device) is added to each milk tank.
The material of the tank is made of high-quality aluminum alloy and stainless steel. The tank and the tank are finely polished. The tank can be equipped with heat preservation and refrigeration functions. It can transport a variety of chemical raw materials, dairy products, oil products and liquid food transportation.
The tank can be set to multiple positions according to the demand, and a variety of media can be dispensed at any time, so that the pump can be pumped in and out, and the table can be over-extended, but the table and the self-flowing table can be used.
The technical advantages of CLW brand stainless steel milk tanker semitrailer manufactured by Chengli Special Automobile Co., Ltd. is as below.
1. The tank body is made of 3mm/4mm/5mm 304-2B food-grade stainless steel cold-rolled plate material, which is formed by argon arc welding on both sides and then polished and polished to make the inside of the tank smooth and flat without sharp angles.
2. The thermal insulation material uses polyurethane foam for thermal insulation, and 10mm rubber sponge is added to further enhance the thermal insulation effect.
3. The outsourcing of the tank body is made of lapped stainless steel wire drawing board, which has a bright appearance and is easy to clean.
4. The chamber is equipped with a CIP automatic cleaning device, and the internal cleaning ball is automatically cleaned.
5. The tank body can be designed to be divided into warehouses to meet the different transportation needs of different users and realize multiple transportation at one time.
6. Straight-through upper platform walkway, non-slip pattern aluminum plate design, convenient for staff to operate, safer and more reliable,
7. The cone-shaped head design makes the head more sturdy in the quality of the body and safer to drive.
If you're interested in our milk tanker, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: 0086 13329899995.
1, Manhole; 2, CIP cleaning ball; 3, auto- breather valve; 4, CIP cleaning butterfly valve; 5, discharging milk outlet; 6, Self-cleaning outlet; 7, stainless steel exterior cover; 8, PU Foam; 9, tanker wall with foodgrade 304-2B stainless steel material
More pictures of triple axles 33cbm fresh milk tanker trailer as below.
customized triple axles 33tons fresh milk tanker tanker trailer for sale
Main technical parameters of triple axles 33cbm milk tanker semitrailer manufactured by Chengli Special Automobile Co., Ltd. Is as below.
| Triple axles 33cbm milk tanker semitrailer for sale(stainless steel material) main parameters |
| Truck model |
CLW9403GNYXN |
| Milk tanker volume |
33,000Liters(33cbm) |
| Overall dimension(L*W*H) |
10370*2500*3650(mm) |
| Total mass |
40000kgs |
| Curb mass |
7800kgs |
| Rated loading capacity |
32200kgs |
| Tractor head |
Client can choose the suitable tractor head |
| Truck axles |
High quality FUWA/BPW |
| wheelbase |
4750+1310+1310(mm) |
| Tire specification |
12R22.5 |
| Tanker wall material |
Foodgrade stainless steel material 304-2B |
| Insulating material |
80mm PU foam |
| Exterior cover material |
Stainless steel material |
| More information, please send email to chenglitruckanita@hotmail.com or Whatsapp/Wechat/Mob.: 0086 13329899995. |
