Customized SINO TRUK HOWO 4*2 RHD12CBM garbage compactor truck for sale, compacted garbage truck for KENYA
Customized SINO TRUK HOWO 4*2 RHD 160hp diesel 12cbm garbage compactor truck, adotps SINO TRUK HOWO RHD 2080mm one row and a half driver cab, 4700mm wheelbase, YC4E160-33 yuchai 160hp diesel engine, 6 speed gearbox, 3.6tons front axle/10.5tons rear axle, 9.00R20 rail tires, power steering, air cut braking, engine brakes, etc.
The volume of SINO TRUK HOWO 160hp diesel garbage compactor truck is about 12cbm. and with the wastes loading capacity of about 8tons-10tons. The wastes van of CLW Brand compacted garbage truck adopts high quality China standard light duty steel, solid arc-shape box body of strengthen beam and steel plate welded.
Operation way: PLC control system; loading and discharging way: rear loading wastes bins mechanism; compacting way: Bi-directional compression; wastes compacting density≥0.8T/m³; one working circle time for loading and discharging ≤30s; max compressing force≥150KN; max passing force≥180KN.
If you're interested in our garbage compactor truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.:0086 13329899995.
More pictures of SINO TRUK HOWO 4*2 RHD 160hp diesel 12cbm garbage compacted vehicle as below.
Main technical parameters of SINO TRUK HOWO Light duty 12cbm garbage compactor truck is as below.
| 1 |
Product name |
SINO TRUK HOWO 4*2 RHD 12m3 garbage compactor truck for sale |
| 2 |
Truck chassis model |
ZZ |
| 3 |
Overall dimension(L*W*H) |
9000×2500×3300 |
| 4 |
Total mass(kgs) |
18000 |
| 5 |
Curb mass(kgs) |
10680 |
| 6 |
Rated mass(kgs) |
7315 |
| 7 |
Volume |
12m3 |
| 8 |
Real loading capacity |
About 8-10tons |
| 9 |
Max speed |
90kw/h |
| 10 |
Wheelbase |
4700 |
| 11 |
Axle nos. |
2 |
| 12 |
Driver cab |
SINO TRUK HOWO RHD 2080mm one row and a half driver cab |
| 13 |
Approach/departure angle(°) |
19/17 |
| 14 |
Front/rear suspension (mm) |
1330/2770 |
| 15 |
Front/rear tread(mm) |
1980/1860 |
| 16 |
Tire specification |
9.00R20*6 |
| 17 |
Spring |
3/9+8 |
| 18 |
Engine model |
YC4E160-33 |
| 19 |
Rated power |
118KW/160hp |
| 20 |
Displacement(ml) |
4257ml |
| 21 |
Fuel type |
Diesel |
| 22 |
Emission standard |
Euro 3 |
| 23 |
Gearbox |
6 speed gearbox, manual |
| 24 |
Front/rear axle |
3.6tons/10.5tons |
| 25 |
Color |
Different color upon request |
| 26 |
Wastes van |
Solid arc-shape box body of strength beam and steel plate welded |
| 27 |
Wastes van material |
High quality China standard light duty steel |
| 28 |
Operation way |
PLC control way |
| 29 |
Loading and discharging way |
Rear overturning mechanism |
| 30 |
Compacted way |
Bi-directional compression |
| 31 |
Wastes compacting density |
≥0.8tons/m3 |
| 32 |
One working circle time for loading and discharging |
≤30s |
Garbage trucks are widely used in sanitation, municipal, factory and mining enterprises, and residential areas where have a lot of garbage. Garbage trucks are classified into compressed garbage trucks, swing arm type, dump type, sealed type, docking type, hook type arm type, and pull arm type garbage truck. Garbage trucks can carry multiple compartments in one vehicle, which can effectively prevent secondary pollution during the loading and unloading process. The modified part is separable from the original car chassis, which is easy to maintain and maintain the mobility and driving performance of the original car. Customers who have special requirements for garbage trucks please contact with us at any time. We can produce the trucks according to your requirements.
Our CLW brand garbage compactor truck for sale is constructed with 12# low alloy steeland 5mm, 4mm, 10mm steel.The body is fitted on the chassis by the truck beam.The body floor is fully sealed.All the sewage can go directly into the sewage tank,so as not to corrode the body and chassis .Moreover,it can also prevent the sewage leakage while the truck is driving on the road and avoid the secondary pollution.
The waste truck compactor usually compacts the waste using a hydraulically powered mechanism that employs a moving plate or shovel to scoop the waste out from the loading hopper and compress it against a moving wall. In most compactor designs, the plate has a pointed edge (hence giving it the industry standard name packer blade) which is designed to apply point pressure to the waste to break down bulky items in the hopper before being drawn into the main body of the truck.
There are three kinds of mechanism options available to the customer,barrel turnover mechanism,panel turnover mechanism and tipping mechanism.by the use of hydraulics,the barrel is locked during the overturning process,which is very safe and reliable.
