Customized FOTON 4*2 LHD 240Hp diesel 12-14cbm garbage compactor truck for sale, HOT SALE! best price compacted garbage truck
CLW Brand garbage compactor trucks are also called rear loader garbage truck, wastes collecting vehicles, etc. This kind of garbage truck is a kind of special purpose vehicle, mainly used for collecting, transporting and discharging bagged wastes, barreled wastes, bulk household wastes in towns and cities, etc.The wastes is pressured and pushed into the wastes van by the truck mounted wastes propeller (also called negative pressure mechanism), so that making the wastes distributing into the tank evenly and higher density and till full.The collecting and transporting way of the garbage compactor truck adopts widely all over the world. The function of the entire special device adopts the truck engine as power, realizing by hydraulic mechanism manual or electronic control.The wastes van and the loader, which is also called wastes tan and sewer tank, adopting high quality carbon steel with full-sealed welding structure, with the advantages of high strength, light weight, non second pollution, etc. More information, please contact with Ms. Anita.
Customized FOTON 4*2 LHD 240hp 12cbm-14cbm garbage compactor truck, adopts FOTON AUMARK 4*2 LHD driver cab, 4800mm wheelbase, 8 speed manual gearbox, 10tons rear axle, YC6A240-33 177KW/240hp diesel Euro 3 engine, 11R22.5 rail tires, etc.
The volume of the compactor garbage van is 12-14m3,and with the wastes loading capacity of about 10-12tons. THe wastes van of CLW Brand compacted garbage truck adopts high quality China standard light duty steel, solid arc-shape box body of strengthen beam and steel plate weled.
Operation way: PLC control system; loading and discharging way: rear loading wastes bins mechanism; compacting way: Bi-directional compression; wastes compacting density≥0.8T/m³; one working circle time for loading and discharging ≤30s; max compressing force≥150KN; max passing force≥180KN.
If you're interested in our compacted garbage truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: 0086 13329899995.
More pictures of FOTON 12cbm garbage compactor truck manufactured by Chengli Special Automobile Co., Ltd. is as below.
customized FOTON AUMAN 12cbm compacted garbage truck for sale
The specification of FOTON 4*2 LHD 12-14CBM garbage compactor truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| 1 |
Product name |
FOTON 4*2 LHD garbage compactor truck for sale(12cbm-14cbm)
|
| 2 |
Truck chassis model |
BJ
|
| 3 |
Overall dimension(L*W*H) |
8330×2500×3400
|
| 4 |
Total mass(kgs) |
16000 |
| 5 |
Curb mass(kgs) |
10805 |
| 6 |
Driver cab person |
3 included the driver |
| 7 |
Volume |
12m3-14m3 |
| 8 |
Real loading capacity |
About 10tons-12tons |
| 9 |
Max speed |
90kw/h |
| 10 |
Wheelbase |
4800 |
| 11 |
Axle nos. |
2 |
| 12 |
Driver cab |
FOTON AUMARK 4*2 LHD driver cab |
| 13 |
Approach/departure angle(°) |
22/14 |
| 14 |
Front/rear suspension (mm) |
1365/2465 |
| 15 |
Front/rear tread(mm) |
1883/1847 |
| 16 |
Tire specification |
11R22.5 |
| 17 |
Spring |
10/10+8 |
| 18 |
Engine model |
YC6A240-33 |
| 19 |
Rated power |
176KW/240hp |
| 20 |
Displacement(ml) |
7000ml |
| 21 |
Fuel type |
Diesel |
| 22 |
Emission standard |
Euro 3 |
| 23 |
Gearbox |
8 speed gearbox, manual |
| 24 |
Front/rear axle |
10tons rear axle |
| 25 |
Color |
Different color upon request |
| 26 |
Wastes van |
Solid arc-shape box body of strength beam and steel plate welded |
| 27 |
Wastes van material |
High quality China standard light duty steel |
| 28 |
Operation way |
PLC control way |
| 29 |
Loading and discharging way |
Rear overturning mechanism |
| 30 |
Compacted way |
Bi-directional compression |
| 31 |
Wastes compacting density |
≥0.8tons/m3 |
| 32 |
One working circle time for loading and discharging |
≤30s |
| 33 |
Max compressing force |
≥150KN |
| 34 |
Max passing force |
≥180KN |
