Hot sale!SINO TRUK HOWO 6*4 LHD 336hp diesel 20cbm garbage compactor truck for sale,Good price refuse rear loader garbage truck for sale
Customized SINO TRUK HOWO 6*4 LHD 20CBM garbage compactor truck, adopts HW76 new face LHD driver cab, 4325+1350mm wheelbase, HW13710 10 speed manual gearbox, HW70 PTO, HF7 7tons front axle/ ST16 16tons rear axles, ZF8198 steering gear, 295/80R22.5 tires,weichai 336hp diesel engine, etc.
The volume of SINO TRUK HOWO 336hp diesel garbage compactor truck is about 20cbm. and with the wastes loading capacity of about 10-12tons. The wastes van of CLW Brand compacted garbage truck adopts high quality China standard light duty steel, solid arc-shape box body of strengthen beam and steel plate welded.
Operation way: PLC control system; loading and discharging way: rear loading wastes bins mechanism; compacting way: Bi-directional compression; wastes compacting density≥0.8T/m³; one working circle time for loading and discharging ≤30s; max compressing force≥150KN; max passing force≥180KN.
CLW Brand garbage compactor trucks are also called rear loader garbage truck, wastes collecting vehicles, etc. This kind of garbage truck is a kind of special purpose vehicle, mainly used for collecting, transporting and discharging bagged wastes, barreled wastes, bulk household wastes in towns and cities, etc.The wastes is pressured and pushed into the wastes van by the truck mounted wastes propeller (also called negative pressure mechanism), so that making the wastes distributing into the tank evenly and higher density and till full.The collecting and transporting way of the garbage compactor truck adopts widely all over the world. The function of the entire special device adopts the truck engine as power, realizing by hydraulic mechanism manual or electronic control.The wastes van and the loader, which is also called wastes tan and sewer tank, adopting high quality carbon steel with full-sealed welding structure, with the advantages of high strength, light weight, non second pollution, etc.
If you're interested in our garbage compactor truck, please send email to truck0011@163.com or talk to Anita by Whatsapp: 0086 13329899995.
Main technical parameters of SINO TRUK HOWO 6*4 LHD 20cbm garbage compactor truck is as below.
| 1 |
Product name |
SINO TRUK HOWO 6*4 LHD 20m3 garbage compactor truck for sale
|
| 2 |
Truck chassis model |
ZZ1257
|
| 3 |
Overall dimension(L*W*H) |
10025×2496×3400
|
| 4 |
Total mass(kgs) |
25000 |
| 5 |
Curb mass(kgs) |
16050 |
| 6 |
Rated mass(kgs) |
8820 |
| 7 |
Volume |
16m3 |
| 8 |
Max speed |
90kw/h |
| 9 |
Wheelbase |
4325+1350 |
| 10 |
Axle nos. |
3 |
| 11 |
Driver cab |
HW76 new face LHD driver cab |
| 12 |
Approach/departure angle(°) |
16/11 |
| 13 |
Front/rear suspension (mm) |
1500/2850 |
| 14 |
Front/rear tread(mm) |
2022; 1830/1830 |
| 15 |
Tire specification |
295/80R22.5 |
| 16 |
Steel Spring |
9/12 |
| 17 |
Engine model |
WD615.47 |
| 18 |
Rated power |
247KW/336hp |
| 19 |
Displacement(ml) |
9726ml |
| 20 |
Fuel type |
Diesel |
| 21 |
Emission standard |
Euro 2 |
| 22 |
Gearbox |
HW13710 10 speed manual gearbox |
| 23 |
Front/rear axle |
HF7 7tons front axle/ ST16 16tons rear axles |
| 24 |
Color |
Different color upon request |
| 25 |
Wastes van |
Solid arc-shape box body of strength beam and steel plate welded |
| 26 |
Wastes van material |
High quality China standard light duty steel |
| 27 |
Operation way |
PLC control way |
| 28 |
Loading and discharging way |
Rear overturning mechanism |
| 29 |
Compacted way |
Bi-directional compression |
| 30 |
Wastes compacting density |
≥0.8tons/m3 |
| 31 |
One working circle time for loading and discharging |
≤30s |
| 32 |
Color |
White color upon request |
More pictures of SINO TRUK HOWO 6*4 20CBM refuse garbage compactor truck is as below.
