HOT SALE! SHACMAN brand 4*2 LHD 210hp rear loader garbage truck, good price garbage compactor truck for sale
Customized SHACMAN 4*2 LHD 210hp diesel 14cbm-16cbm garbage compactor trucks for sale. Look at the finished pictures of SHACMAN brand 14cbm-16cbm compacted garbage trucks are as below.
SHACMAN brand 4*2 LHD 210hp diesel garbage compactor truck, adopts SHACMAN brand 4*2 LHD L3000 one row and a half driver cab, 5000mm wheelbase, WP6.210E32 weichai 210hp Euro 3 diesel engine, 8JS85T 8 speed manual gearbox, 4.8T front axle/10T rear axle, 200Liters steel oil tanker, 10,00R20 Rail tires, etc.
The volume of the compactor garbage van is 14-16m3,and with the wastes loading capacity of about 11tons-13tons. The wastes van of CLW Brand compacted garbage truck adopts high quality China standard light duty steel, solid arc-shape box body of strengthen beam and steel plate weled.
Operation way: PLC control system; loading and discharging way: rear loading wastes bins mechanism; compacting way: Bi-directional compression; wastes compacting density≥0.8T/m³; one working circle time for loading and discharging ≤30s; max compressing force≥150KN; max passing force≥180KN.
Website: www.trucksinchina.com
Whatsapp/Wechat/Mob.: 0086 13329899995.
Email: truck0011@163.com
More pictures of SHACMAN brand 16cbm garbage compactor truck is as below.
The specification of SHACMAN 4*2 LHD 14cbm-16cbm garbage compactor truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| 1 |
Product name |
SYHACMAN 4*2 LHD garbage compactor truck for sale(14cbm-16cbm) |
| 2 |
Truck chassis model |
SX |
| 3 |
Overall dimension(L*W*H) |
9400×2550×3300 |
| 4 |
Total mass(kgs) |
18000 |
| 5 |
Curb mass(kgs) |
10500 |
| 6 |
Driver cab person |
3 included the driver |
| 7 |
Volume |
14cbm-16m3 |
| 8 |
Real loading capacity |
About 11tons-13tons |
| 9 |
Max speed |
89kw/h |
| 10 |
Wheelbase |
5000 |
| 11 |
Axle nos. |
3 |
| 12 |
Driver cab |
SHACMAN brand 4*2 LHD L3000 one row and a half driver cab |
| 13 |
Approach/departure angle(°) |
23/10 |
| 14 |
Front/rear suspension (mm) |
1450/2850 |
| 15 |
Front/rear tread(mm) |
1970/1860 |
| 16 |
Tire specification |
10.00R20 |
| 17 |
Spring |
8/10+8 |
| 18 |
Engine model |
WP6.210E32 |
| 19 |
Rated power |
155KW/210hp |
| 20 |
Displacement(ml) |
6230ml |
| 21 |
Fuel type |
Diesel |
| 22 |
Emission standard |
Euro 2 |
| 23 |
Gearbox |
8JS85T 8 speed gearbox, manual |
| 24 |
Front/rear axle |
4.8T front axle/10T rear axle |
| 25 |
Color |
Different color upon request |
| 26 |
Wastes van |
Solid arc-shape box body of strength beam and steel plate welded |
| 27 |
Wastes van material |
High quality China standard light duty steel |
| 28 |
Operation way |
PLC control way |
| 29 |
Loading and discharging way |
Rear overturning mechanism |
| 30 |
Compacted way |
Bi-directional compression |
| 31 |
Wastes compacting density |
≥0.8tons/m3 |
| 32 |
One working circle time for loading and discharging |
≤30s |
| 33 |
Max compressing force |
≥150KN |
| 34 |
Max passing force |
≥180KN |
