Customized SINO TRUK HOWO 6*4 LHD 371hp diesel 23cbm garbage compactor truck for South America, Lower price refuse garbage compactor truck supplier in China
HOT SALE! HOWO 23CBM compacted garbage truck
Lower price biggest volume 23cbm rear loader garbage truck for sale
HOT SALE! Customized SINO TRUK HOWO 6*4 371hp diesel 23cbm compacted garbage truck, adopts HW76 new face one row and a half driver cab, 4625+1350mm wheelbase, HW19710 10 speed manual gearbox, WD615.47 371hp diesel Euro 2 engine, HF6 6T front axle/ST16 16T rear axle, 295/80R22.5 tires, 400L oil tanker, etc.
The volume of SINO TRUK HOWO 6*4 371hp diesel garbage compactor truck is 23cbm, the biggest volume we can manufacture.
Operation way: PLC control system; loading and discharging way: rear loading wastes bins mechanism; compacting way: Bi-directional compression; wastes compacting density≥0.8T/m³; one working circle time for loading and discharging ≤30s; max compressing force≥150KN; max passing force≥180KN.
Our CLW brand compactor garbage truck is constructed with 12# low alloy steeland 5mm, 4mm, 10mm steel.The body is fitted on the chassis by the truck beam.The body floor is fully sealed.All the sewage can go directly into the sewage tank,so as not to corrode the body and chassis .Moreover,it can also prevent the sewage leakage while the truck is driving on the road and avoid the secondary pollution.
The waste compression truck usually compacts the waste using a hydraulically powered mechanism that employs a moving plate or shovel to scoop the waste out from the loading hopper and compress it against a moving wall. In most compactor designs, the plate has a pointed edge (hence giving it the industry standard name packer blade) which is designed to apply point pressure to the waste to break down bulky items in the hopper before being drawn into the main body of the truck.
If you're interested in our garbage compactor truck, please send email to truck0011@163.com or talk to Anita by Whatsapp: 0086 13329899995.
main technical parameters of HOWO 371hp 23cbm biggest volume refuse garbage compactor truck is as below.
| 1 |
Product name |
SINO TRUK HOWO 6*4 LHD 23m3 garbage compactor truck for sale
|
| 2 |
Truck chassis model |
ZZ1257
|
| 3 |
Overall dimension(L*W*H) |
10025×2496×3400
|
| 4 |
Total mass(kgs) |
25000 |
| 5 |
Curb mass(kgs) |
16050 |
| 6 |
Rated mass(kgs) |
8820 |
| 7 |
Volume |
16m3 |
| 8 |
Max speed |
90kw/h |
| 9 |
Wheelbase |
4625+1350 |
| 10 |
Axle nos. |
3 |
| 11 |
Driver cab |
HW76 new face LHD driver cab |
| 12 |
Approach/departure angle(°) |
16/11 |
| 13 |
Front/rear suspension (mm) |
1500/2850 |
| 14 |
Front/rear tread(mm) |
2022; 1830/1830 |
| 15 |
Tire specification |
295/80R22.5 |
| 16 |
Steel Spring |
9/12 |
| 17 |
Engine model |
WD615.47 |
| 18 |
Rated power |
273KW/371hp |
| 19 |
Displacement(ml) |
9726ml |
| 20 |
Fuel type |
Diesel |
| 21 |
Emission standard |
Euro 2 |
| 22 |
Gearbox |
HW13710 10 speed manual gearbox |
| 23 |
Front/rear axle |
HF7 7tons front axle/ ST16 16tons rear axles |
| 24 |
Color |
Different color upon request |
| 25 |
Wastes van |
Solid arc-shape box body of strength beam and steel plate welded |
| 26 |
Wastes van material |
High quality China standard light duty steel |
| 27 |
Operation way |
PLC control way |
| 28 |
Loading and discharging way |
Rear overturning mechanism |
| 29 |
Compacted way |
Bi-directional compression |
| 30 |
Wastes compacting density |
≥0.8tons/m3 |
| 31 |
One working circle time for loading and discharging |
≤30s |
| 32 |
Color |
White color upon request |
