Lower price heavy duty HOWO 14CBM rear compacted garbage truck for West Africa, HOT SALE! HOWO 290hp diesel 10T refuse garbage compactor vehicle
SINO TRUK HOWO 4*2 LHD 4*2 LHD 290hp diesel 14cbm garbage compactor truck adopts SINO TRUK HOWO HW76 new face truck head, 4*2 LHD driving, 4600mm wheelbase, WD615.87 123KW/290hp Euro 2 diesel engine, HW13710 10 manual gearbox, HF7 7T front axle/ST16 16T rear axle, 295/80R22.5 tires,400L oil tanker, etc.
The volume of SINO TRUK HOWO 290hp diesel garbage compactor truck is about 14cbm. and with the wastes loading capacity of about 8tons-10tons. The wastes van of CLW Brand compacted garbage truck adopts high quality China standard light duty steel, solid arc-shape box body of strengthen beam and steel plate welded.
Operation way: PLC control system; loading and discharging way: rear loading wastes bins mechanism; compacting way: Bi-directional compression; wastes compacting density≥0.8T/m³; one working circle time for loading and discharging ≤30s; max compressing force≥150KN; max passing force≥180KN.
Our CLW brand compactor garbage truck is constructed with 12# low alloy steeland 5mm, 4mm, 10mm steel.The body is fitted on the chassis by the truck beam.The body floor is fully sealed.All the sewage can go directly into the sewage tank,so as not to corrode the body and chassis .Moreover,it can also prevent the sewage leakage while the truck is driving on the road and avoid the secondary pollution.
The waste compression truck usually compacts the waste using a hydraulically powered mechanism that employs a moving plate or shovel to scoop the waste out from the loading hopper and compress it against a moving wall. In most compactor designs, the plate has a pointed edge (hence giving it the industry standard name packer blade) which is designed to apply point pressure to the waste to break down bulky items in the hopper before being drawn into the main body of the truck.
If you're interested in our garbage compactor truck, please send email to truck0011@163.com or talk to Anita by Whatsapp: 0086 13329899995.
More pictures of SINO TRUK HOWO 4*2 LHD 290hp diesel 14cbm compacted garbage truck, refuse garbage truck is as below.
Good price HOWO 14CBM compacted garbage truck for sale
High quality customized HOWO 290HP 14CBM rear loader garbage compactor turck for sale
Main technical parameters of HOWO 14cbm garbage compactor truck manufactured by Chengli Special Automobile Co., Ltd. is as below.
| 1 |
Truck model |
SINO TRUK HOWO 4*2 LHD garbage compactor truck |
| 2 |
Truck chassis model |
ZZZ1167 |
| 3 |
Engine model |
WD615.87 |
| 4 |
Engine power |
213KW/290hp |
| 5 |
Engine displacement |
9726 |
| 6 |
Engine brand |
Weichai |
| 7 |
Engine emission standard |
Euro 2 |
| 8 |
Oil consumption(L/100km) |
22L |
| 9 |
Max speed |
90kw/h |
| 10 |
mini turning diameter |
18m |
| 11 |
Max Gradability |
25﹪ |
| 12 |
Truck wheelbase |
4600(mm) |
| 13 |
Wastes van volume |
12-14m3 |
| 14 |
Fuel type |
Diesel |
| 15 |
Wastes hopper lifting angle |
≥45° |
| 16 |
Loading and discharging way |
Overturning hopper/wastes bins mechanism |
| 17 |
compacting way |
Bi-directional compression; wastes compacting density≥0.8T/m³ |
| 18 |
one working circle time for loading (s) |
≤22 |
| 19 |
one working circle time for discharging (s) |
≤30 |
| 20 |
Overall dimension(L*W*H) (mm) |
8765×2500×3300 (mm) |
| 21 |
Curb mass(kgs) |
8870 |
| 22 |
max compressing force |
≥150KN, |
| 23 |
Color |
Different color upon request |
