Customized HOWO stainless steel fresh milk storage tanker for sale, Lower price liquid food transported tanker truck for sale
Our milk tanker truck characteristic is as below.
(1). The milk tank is made up of three layers:outside layer(for physical protection),middle layer(thermal insulation),inner layer tank(for milk filling). All pipes and valves are made of stainless steel.
(2). The thickness of thermal insulation layer is 80mm to prevent milk spoilage.
(3). The tanker liner is made of high quality food grade stainless steel,and the inner tank has been fine polished.
(4). Support transportation medium: Milk, drinking water, cooking oil , beer , maltose, maltose, ice cream
(5). Equipped with PIC cleaning devices.With function of thermal insulation: medium temperature change≤1°C during 24 hours.
(6). The tank can be divided into several parts according to demand to load different medium.
(7)Optional compartments, installation of pumps, flowmeters, etc.
The standard device of 5CBM Milk tanker truck manufactured by Chengli Special Automobile Co., Ltd. as below.
3mm thick 304-2B food grade stainless steel;
standard with single one compartment (with one self-discharging valve, we can customized the compartments upon request).
Every compartment with only one set of PIC cleaning device,
the temperature will be changed less than 1 degree within 24 hours;
the exterior thermal insulating layer is with 80mm PU foam material
The milk tanker truck is also called fresh milk transporter, milk tanker, liquid food transporter, mobile liquid food transported vehicle. The tank body is made of food grade stainless steel plate. The outer part of the tank body needs to be used as insulation layer to prevent the deterioration of fresh milk. The inside of the tank body needs smooth and no acute angle. A CIP (cleaning device) is added to each milk tank.
The material of the tank is made of high-quality aluminum alloy and stainless steel. The tank and the tank are finely polished. The tank can be equipped with heat preservation and refrigeration functions. It can transport a variety of chemical raw materials, dairy products, oil products and liquid food transportation.
The tank can be set to multiple positions according to the demand, and a variety of media can be dispensed at any time, so that the pump can be pumped in and out, and the table can be over-extended, but the table and the self-flowing table can be used.
If you're interested in our HOWO brand 5T milk tanker truck, please send email to truck0011@163.com or talk to Anita by Whatsapp; 0086 13329899995.
main technical parameters of SINO TRUK HOWO 5T stainless steel milk tanker truck is as below.
| Product Specifications of 304 stainless steel milk storage tank truck |
| Basic Info. |
Product Name |
5 ton milk truck |
| |
Chassis Brand & Year |
HOWO, 2022 new |
| |
Wheel Drive |
4x2, LHD |
| |
Overall Dimension(mm) |
6020x2300x2585 |
| |
Gross Weight(kg) |
10995 |
| |
Curb Weight(kg) |
4995 |
| |
Wheelbase of Chassis |
3360mm |
| |
Engine Power(KW) |
116 HP diesel engine |
| |
Fuel Type |
Diesel |
| |
Emission Standard |
Euro 3 |
| |
Front Axle Load |
2.4Ton |
| |
Rear Axle Load |
4.2 Ton |
| |
Tire Model & Number |
7.00R16, |
| |
Cab |
HOWO 1880 standard cabin |
| |
Transmission |
WLY6T46 |
| |
Steering System |
Power steering |
| |
Max Speed |
95km/h |
| Body |
volume |
5m3 1 compartment |
| |
Material of Box |
Inner side: 4mm 304-2B food-grade stainless steel
Middle: 60-100mm Polyurethane foam insulation
Outer side: 1.2mm 201 stainless steel
|
| |
Feartures |
1. CIP auto-cleaning with cleaning angles
2. Use food-grade polished stainless steel for parts that touch with milk
3. Optimized tank design to minimize milk remaining.
4. Thick polyurethane foam insulation to ensure 24h temperature change <1℃
|
| |
Valve and pipeline |
All valves and pipeline are made of stainless steel |
| |
Pump |
60/30 |
More pictures of SINO TRUK HOWO 5T milk tanker truck is as below.
Chengli Special Automobile Co., Ltd,which is appointed by government ,top 500 enterprise company of China ,is the biggest special vehicle manufacture in China.Our trucks occupy an important share in the domestic and international market,more than 20 years manufacturing and export experience.
Tank truck is our mainly products include milk transport truck .The tank material is made by food grade stainless steel,.It is for fresh milk transport and short-time storage.We produce milk truck from 3m3-35m3,and milk trailer from 35m3-55m3
.According to the use of tankers,customers can choose driving model 4*2,4*4,6*2,6*4,6*6,8*4.Chassis brand optional Dongfeng Foton JAC JMC FAW CAMC IVECO ISUZU SINOTRUK Hino Shacman etc.
centrifugal pumps, gear pump, copper gear pump, stainless steel pump, it has big flow,fast speed of suction .
Also customer can customize the compartment of the tank ,each compartment equipped with independent discharging system,can load different liquid foods at the same time.
Our tank material is very strictly , 304-2B inner tank material is food grade stainless steel 4mm thick, imported insulation layer of polyurethane foam insulation 8CM, Outer tank material 304 stainless steel 2mm,can make the temperature elevating ≤1 ℃ within 24 hours medium ,all the parts which touch with milk need to be stainless ,and equipped with auto -cleaning PIC cleaning system 360° for each compartment , easy for the inner tank washing.Our tank truck can load Milk, drinking water, cooking oil , beer , maltose, maltose, ice cream etc.It is with the performance of Light weight and good heat preservation effect.
I think we can supply you the best and professional service with satisfied price . Look forward to our long term cooperation.
