ASME factory price CLW brand 100,000L bulk lpg gas storage tank for sale, best price 100m3 surface lpg gas storage tank
our factory is a professional LPG tank manufacturer in China, our products
fully passed ISO9001-2000 international quality system and 3C authentication.
1. we have the biggest LPG trailer in the world, the valid volume is 58.5cbm;
low transport costs, more profit. And the smallest volume is 40.5cbm;
2. we have the biggest LPG truck in China, it's valid volume is 35.5cbm; And the smalles volume is 5.5cbm;
3. our LPG storage tank ranged from 5cbm to 200cbm. both on the floor ones
and in the ground ones.
4 It is used for storing gas, liquid, and vapour mediums, for example, propane,
propene,dimethyl ether ,liquid ammonia ,
methylamine,aldehyde and other mediums.It is widely used in oil, chemical
industry, machinery, electric power areas.
5 .A, B Class 100% ray weld inspection, II level qualified C, D Class welds
100% magnetic particle inspection, I level qualified
6, Our CLW brand pressure vessels have been passed ASME(American Society of Mechanical Engineers).
If you're interested in our lpg gas pressure vessels, please feel free to send email to truck0011@163.com or talk to Anita directly by whatsapp/wechat/Mob.: +86 13329899995.
Product Description
|
|
LPG STORAGE TANK SPECIFICATION (surface lpg gas tank)
|
|
|
Capacity
(CBM)
|
Diameter
DN
|
Shell thickness
(mm)
|
Head thickness
(mm)
|
Kerb weight
(kg)
|
Loading
Weight
(kg)
|
Overall dimension(mm)
|
|
|
5
|
1600
|
10
|
10
|
2030
|
1995
|
3070*1620*2210
|
|
|
8
|
1600
|
10
|
10
|
2540
|
3192
|
4270*1620*2210
|
|
|
10
|
1600
|
10
|
10
|
2950
|
3990
|
5260*1620*2210
|
|
|
12
|
1800
|
10
|
12
|
3360
|
4788
|
5034*1820*2410
|
|
15
|
15
|
1800
|
10
|
12
|
3920
|
5985
|
6224*1820*2410
|
|
|
20
|
1800
|
10
|
12
|
4820
|
7980
|
8174*1820*2410
|
|
|
25
|
2200
|
12
|
14
|
6020
|
9975
|
7008*2224*2814
|
|
|
32
|
2400
|
14
|
14
|
7710
|
12768
|
7508*2428*3018
|
|
|
50
|
2600
|
14
|
16
|
10910
|
19950
|
9912*2628*3218
|
|
|
50
|
2700
|
14
|
16
|
10640
|
19950
|
9182*2728*3318
|
|
|
80
|
3100
|
16
|
18
|
17000
|
31920
|
11166*3132*3722
|
|
|
80
|
3200
|
18
|
18
|
18140
|
31920
|
10516*3236*3826
|
|
|
100
|
3100
|
16
|
18
|
20410
|
39900
|
13866*3132*3722
|
|
|
100
|
3200
|
18
|
18
|
21800
|
39900
|
13016*3236*3826
|
|
|
120
|
3400
|
18
|
20
|
24960
|
47880
|
13820*3436*4026
|
|
Design pressure
|
1.77MPa
|
|
Corrosion allowance( mm)
|
1mm
|
|
Medium density (kg/m3)
|
420kg/m3
|
|
Material of tank and main pressure parts
|
Q345R
|
|
Carried standard
|
Pressure vessels,supervision regulation on safety technology
for stationary pressure vessels
|
|
Safety valve of selection fitting
|
Safety valve, column magnetic reversible level meter,pressure
gauge,thermometer,cut-off valve
|
Remark:
1 The safety valve is designed under the condition that the tank
is placed under spray device whose flow is larger than 10L/m.min
2 The location dimension of pipe orifice can be setted by the user’s actual place .
3 We can change reversible level meter to magnetic float ball type
according to the user’s requirement.
4 The data list is only for reference ,take the drawing as accuracy.
More pictures of CLW brand ASME bulk lpg gas storage tanks manufactured by CLW Special Automobile Co., Ltd.
More information, please feel free to contact with Ms. Anita Deng.
