Place of Origin: | China |
Brand Name: | CLW |
Certification: | US ASME standard, China standard |
Minimum Order Quantity: | 1 |
---|---|
Price: | negotiable |
Packaging Details: | in bulk package |
Delivery Time: | 35 days |
Payment Terms: | T/T |
Supply Ability: | 20 untis |
Color: | Different Color Upon Request | Price: | High Quality Factory Direct Sale Price |
---|---|---|---|
Material: | High Quality Q345R Material For Lpg Gas Pressure Vessels |
hot sale dongfeng LHD 95hp 5500L bulk lpg gas delivery truck, best price 5.3M3 bulk lpg gas dispensing truck for sale
Small liquefied petroleum gas tank, 5.5m3 lpg gas tank, 95hp lpg gas tank truck sales
China truck manufacturer Chengli Special Automobile Co.,Ltd supply small liquefied petroleum gas tank, 5.5m3 lpg gas tank, 95hp lpg gas tank truck sales.
pressure vessel tank for LPG summary:
1.Domestic or imported High quality Safety accessories is optional for LPG storage tank,the tank volume capacity optional from 10 M3 to 115 M3.
2.According to strict manufacturing engineering to guarantee the lowest rate of contraction and highest dimensional stability.
3.Strict quality testing:A and B class weld joint with 100% x-ray radiographic inspection grade II qualified;C and D class weld joint with 100% magnaflux inspection class I qualified.
4.Anti-corrosion coating on the LPG tank surface.Using sand-blasting treatment, spraying, blowing and other advanced technology.
5.We can accept custom design to meet the conditions of many other gas transport. Transport medium include liquid ammonia, liquid sulfur dioxide, propylene, propane, liquefied petroleum gas (LPG), dimethyl , normal butane, isobutane, butene, isobutene, butadiene and ethylene oxide.
6.Standard configuration: Safety valve, level gauge, pressure gauge, thermometer, emergency shut-off valve, valve boxes, fire extinguishers, fire star cover, antistatic grounding tape, fencing, tires and fenders.
If you're interested in our lpg gas truck, please feel free to send email to truck0011@163.com or talk to Anita directly by whatsapp/wechat/Mob.: +86 13329899995.
main technical parameters of smaller liquefied petroleum gas truck manufactured by Chengli Special Automobile Co., Ltd. as below.
Truck Technical Specifications | ||||||||
Item Name | Small liquefied petroleum gas tank, 5.5m3 lpg gas tank, 95hp lpg gas tank truck sales | Horse Power | 95hp/70kw | |||||
Fact Cubage | 5.5m3 | Overall Dimensions | 5900×2045×2600 mm | |||||
Engine Model | CY4102-C3F | Wheel Base | 3300mm | |||||
LPG Tank Technical Specification | ||||||||
Tank | Overall dimensions (length*diameter) | 3059×1620 mm | Version | Magnetic | ||||
Nominal pressure | 2.5 Mpa | |||||||
Vessel type | III | Scope of testing | 50-2300 mm | |||||
Designing pressure | 1.77 Mpa | Precision | 2.5 | |||||
Working pressure | 1.61 Mpa | Safety Valve | Model | ZGM2.3/2.5 | ||||
Designing temperature | -19~50℃ | Version | Quick joint | |||||
Filling medium | Propane | Nominal pressure | 3.3 Mpa | |||||
Corrosion margin | 1.0 mm | Nominal diameter | DN80 | |||||
Volume | 5.5 m3 | Opening pressure | 1.86-1.94Mpa | |||||
Heat treatment | Bulk | Re-seating pressure | ≥1.35 Mpa | |||||
Filling factor | 420 kg/m3 | Handling System | Feed pipe | DN80 | ||||
Meterials | Q345R | Drain pipe | DN80 | |||||
Hydraulic test pressure | 2.66 Mpa | Admission port | DN50 | |||||
Gas tight test pressure | 1.77 Mpa | Sewage outfall port | DN80 | |||||
Cylinder thickness | 13.56 mm | Vent nozzle port | DN80 | |||||
Head thickness | 13.53 mm | Standard | GB150-1998"Pressure Vessels" | |||||
Service life | 10 years | |||||||
Closing time | ≤10s | "Safety regulation of pressure vessel" | ||||||
Melting close temperature | 70±5℃ |
More pictures of bulk lpg gas delivery trucks manufactured CLW Special Automobile Co., Ltd.
bulk lpg gas dispensing truck for sale
5500L CLW brand lpg gas dispensing truck for sale
