factory direct price CLW brand 25tons lpg tank for sale, ASME standard 25metric tons lpg gas storage tank for sale
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas tank, lpg gas trailer, lpg gas delivery truck, lpg gas dispenser truck, etc. in China since 2004s. With many years' development, our lpg gas pressure vessels products have been exported to so many coutnries all over the world. And our CLW brand lpg gas pressure vesseles become the No.1 selling in China. Most of our lpg gas pressutre vessels are exported aboard. More information, please feel free to contact with Ms. Anita Deng.
If you're interested in our lpg gas pressure vessels, please feel free to send email to truck0011@163.com or talk to Anita directly by wahtsapp/wechat/Mob.: +86 13329899995.
Today, we will introduce the hot sale 25ton lpg gas tanks manufactured by Chengli Special Automobile Co., Ltd. as below.
The main parameters of 65,000L surface lpg gas storage tank for sale
|
Item
|
Unit
|
Main parameters
|
|
Product name
|
|
LPG gas storage tank(65000L)
|
|
Product model
|
|
CLG2700-65
|
|
Loading medium
|
|
LPG gas (propane)
|
|
Overall dimension(L*W*H)
|
mm
|
11832*2728*3318
|
|
Tank dimension(inner diameter*thickness*length)
|
mm
|
DN2700*14*11832
|
|
Tank volume
|
m3
|
65
|
|
Tank thickness
|
mm
|
14
|
|
End heads thickness
|
mm
|
16
|
|
Curb mass
|
kg
|
13590
|
|
Rated mass
|
Kg
|
25935
|
|
Designed pressure
|
Mpa
|
1.77
|
|
Working pressure
|
Mpa
|
≤1.6
|
|
Working temperature
|
℃
|
≤50
|
|
Hydraulic test pressure
|
Mpa
|
2.22
|
|
Air tight test pressure
|
Mpa
|
1.77
|
|
Tank and main Material pressure components
|
Q345R,16Mnlll
|
|
Standard
|
<<GB150steel pressure vessel>>,<<Supervision Regulation on Safety Technology for Pressure Vessel>>
|
|
Chosen assembly
|
Safety valve, magic level gauge, pressure gauge, temperature gauge, cut-off valve, etc.
|
More pictures of 25metric tons lpg gas tankers as below.
clw brand 25tons surface lpg gas storage tank for sale
best price 25tons lpg gas tank
surface lpg gas storage tank for sale
we have the biggest LPG trailer and LPG truck in the world:
1. we have the biggest LPG trailer in the world, the valid volume is
58.5cbm; low transport costs, more profit.
2. we have the biggest LPG truck in China, it's valid volume is
35.5cbm;
3. our LPG storage tank ranged from 10cbm to 100cbm. both on the floor
ones and in the ground ones.
We have made the national A2, C2 three types of pressure vessel manufacturing qualification, to obtain export certification and export qualification. Companies with advanced equipment including automatic submerged arc welding machine, large underwater plasma cutting machine, rolling machine and other forming large tank. Testing equipment including ultrasonic flaw detector, X-ray detectors, magnetic detectors, equipped with heat treatment and testing rooms.
