Place of Origin: | China |
Brand Name: | CLW brand |
Certification: | CCC, ISO 9001 |
Minimum Order Quantity: | 1 unit |
---|---|
Price: | negotiable |
Packaging Details: | in bulk package, waxed |
Delivery Time: | 35 days |
Payment Terms: | T/T, L/C, |
Supply Ability: | 10 units/month |
Color: | Different Color Upon Request | Price: | High Quality Factory Direct Sale Price |
---|---|---|---|
Manufacturing Standard: | Chin Standard Or ASME Standard |
best price CLW brand stationary bullet type 50,000L surface lpg gas storage tank for sale, high quality and good price 50m3 surface propane gas tanker
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessels in China. With many years’ development, Chengli Special Automobile Co., Ltd., could manufacture and sell surface lpg gas storage tank, underground lpg gas storage tank, skid lpg gas refilling station, lpg gas trailer, lpg gas truck, etc. And our CLW brand lpg gas pressure vessels have been exported to Vietnam, Mongolia, Kazakhstan, Uzbekistan, Bangladesh, Korea, Russia, Afghan, Iraq, Angola, Algeria, Nigeria, Congo, Libya, Jordan, Ethiopia, Mozambique, Mali, Niger, Trinidad, Namibia, etc.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of LPG gas storage tank, LPG gas tank, etc. And the CLW LPG gas storage tanks volume are from 5 cubic meter to 120 cubic meter.The lpg storage tank is made of special material Q345R.
As a professional lpg tank manufacturer in China, we have the aptitude to design and manufacture A2 type of pressure vessel, C2 type of lpg tank truck, C3 type of LPG tank container. The manufacturing processing of lpg tank is complex and strict. All the lpg gas tanks must do nondestructive examination, air tight test, hydrostatic test and any other inspections.
If you're interested in our lpg gas storage tanker, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
The hot sale CLW brand China standard 50,000L bullet type stationary surface lpg gas storage tank for Nigeria. as below
best price hot sale 50m3 surface lpg gas storage tank
factory direct sale price CLW Brand surface lpg gas storage tank
The specification sheet of pressure vessel product data sheet
Equipment catalogue | Stationary pressure vessel | Varieties of pressure vessel | Storage | ||||||
Product name | LPG (propane) storage tank | Product no. | G150208 | ||||||
Equipment no. | / | Category of pressure vessel | Ⅲ class | ||||||
Product standard | GB150 NB/T47042 | Designed working life | 15 | ||||||
Main data | Volume | 65m3 |
Internal diameter
|
2700mm | Tank length | 11832*3318mm | |||
Material | Body | Q345R | Thickness | Body | 14mm | Body weight | 11749kg | ||
Head | Q345R | Head | 16mm | Inside components weight | /kg | ||||
Lining | / | Lining | /mm | Filling weight | 25935kgs | ||||
Interlining | / | Interlining | /mm | ||||||
Designed pressure | Shell side | 1.77Mpa | Designed pressure | Shell side | 50 ℃ | Max working pressure | Shell side | / | |
Tube side | /Mpa | Tube side | /℃ | Tube side | / | ||||
Interlining side | /Mpa | Interlining side | /℃ | Interlining side | / | ||||
Medium of shell side | Liquid petroleum gas(propane) |
Medium of tube side
|
/ | Medium of interlining side | / | ||||
Form of structure | Main structure form | Ellipse head, round body | Installation | Fixed horizontal installation | |||||
Bearing type | Saddle support | Heat preservation heat insulation way | - | ||||||
Testing | Method of non-destructive testing | RT PT | Non-destructive testing rate | 100% | |||||
Pressure test type | Hydrostatic test | Puncture test pressure | 2.22MPa | ||||||
Heat treatment method | Stress relieving heat treatment | Heat-treatment temperature | 620±15℃ | ||||||
Safety accessories | |||||||||
Name
|
Type | Size | Quantity | Self-contained | |||||
Magnetic flap liquid level | UZFAI-2.5RF-2940-0.50 | DN25 | 1 | HG21584 | |||||
Safety valve | A42F-25 | DN100 | 1 | GB12243, Pz=1.69MPa, K=0.65 | |||||
Pressure gage | Y-150 | M20×1.5 | 1 | 0-4MPa, 1.6 grade | |||||
Thermometer | WTQ-280 | M33×2 | 1 | -40℃-60℃, 1.5 grade | |||||
Manufacture and supervisory situation | Supervisory | Hubei Institute of Special Equipment Inspection And Test | |||||||
Organization code | 42000423-5 | Organization Verification Certificate N0. | TS711-215-2019 |
